Self-Priming Chemical Pump PD-132 (50Hz)
Negotiable
1 (Min. Order)
You May Like
Product Details
| Place of Origin | Taiwan, China | Brand Name | Showfou | |
| Model Number | PD-132 | Usage | Other, Chemical | |
| Power | Electric | Fuel | Other, Motor |
Product Description
Specifications
1. Made in Taiwan.2. High efficiency.
3. Self-priming Pump.
Features:
- Tough construction against High Corrosive and High Temperature Chemical Liquids due to Adopting (TEFLON BELLOW SEAL) with Self-cooling Design.
- Showfou provide FRPP pump body to meet customer's requirement. FRPP : Fiber Reinforced Polypropylene.
- Special main shaft. ---The sus304 main shaft are covered with Teflon to resist high corrosive chemical liquids.
- Self-priming ability. ---Excellent self-priming ability can suck the liquid up to 6 meter, and the flap valve design can prevent liquid back flow to maintain the flow rate.
- Teflon Bellow Seal. --- Adopting " Teflon Bellow Seal" and Superior anti-corrosive construction to correspond most of chemical liquids such as strongacid and alkali, and the pump lower cover adopting with self-cooling design to prevent the " Teflon below seal " from damage.
| Model | PD-132 (50Hz) |
| S.G. | 1.0 |
| Motor >> Power--Kw (HP) | 0.75 (1) |
| Motor >> Phase (PH) | 3 |
| Motor >> Volt (V) | 220 ~ 480 |
| Pump >> Bore Size--Inlet inch (mm) | 1½" (40) |
| Pump >> Bore Size--Oulet inch (mm) | 1½" (40) |
| Pump >> Max. Head (m) | 12 |
| Pump >> Max. Flow (m³/min) | 0.20 |
| Weight (KG) | 26 Kilogram (Kg) |
| Height (mm) | 374 mm |
| Pump Dia. (mm) | 625 mm |
Dimensions:
