Product Details

Condition	New	Type	Roller Crusher
Capacity(t/h)	2-140	Place of Origin	Henan, China
Brand Name	Great Wall	Model Number	PG
Application	Mining material

Product Description

Specifications

Large Roller Crusher
1.Easy operation
2.Reliable performance
3.Short downtime maintenance time
4.ISO9001:2008

Great Wall Make Great Machine

I. Large Roller Crusher Usage and Application

It is widely used for secondary and fine crushing in the industry of mining, building materials, chemical industry, metallurgy and so on. It can crush materials in middle hardness such as rocks, ore, coke, lump coal, slag, mineral slag, cement clinker, fireproof materials, and so on.

II. Large Roller Crusher Working Principle
The motor drives the fixed roller and movable roller to work via reducer, V-belts or coupling. Materials are put into the space between the two rollers via the feed entrance. As the two rollers inward turning, the input materials are crushed, pressed, ground, and at last come out from the base of the machine.

III. Large Roller Crusher Features

1. Compact structure, low noise and efficient;
2. Easy to install and only need simple foundation;
3. Can adjust the pressure and size easily.
4. Self-protection, the parts can not be damaged when hard materials such as the metals goes into the crushing cavity;
5. Low cost maintenance and easy to maintain.

IV. Large Roller Crusher Main Specifications

Model	Feeding Size (mm)	Output Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Overall Dimension (mm)
2PG400×250	<35	≤2-8	2-10	2×5.5	1.3	2110×870×810
2PG610×400	<65	≤2-20	5-20	2×15	3.9	3510×1420×1030
2PG750×500	<75	≤2-25	10-40	2×18.5	9.5	4210×1630×1260
2PG800×600	<80	≤2-25	12-45	2×22	10.8	4505×1780×1320
2PG1000×700	<100	≤3-30	20-65	2×30	14.9	5310×2175×1595
2PG1200×800	<120	≤3-35	35-80	2×37	25.5	6290×2270×1870
2PG1500×800	<130	≤3-45	50-120	2×75	33.7	7460×2410×2290
2PG1600×1000	<150	≤3-50	60-140	2×90	41.2	8220×2680×2475
