Factory Sale Full Digital Automatic Double Pulse Multiprocess MIG MAG Welder MIG Welding Machine MIG-350P 350AMP
- Ningbo/Shanghai China
- T/T Credit Card
You May Like
-
LCD Display Mig/Mag,Pulse Mig/Mag,Double Pulse Mig/Mag,CO2,Tig,Pulse Tig,MMA Full Digitization Welding Machine
-
Full Digital Mig Mag Tig Co2 Mma Carbon Arc Gouging Welding Machine MIG 500
-
2013 New Digital Inverter Advanced Pulse Inverter Tig Mig Mma Welding Machine
-
2013 New Digital Inverter Advanced Pulse Mig&TIG&MMA Welding Machine DSP Mig Welder
-
Best Quality Inverter Pulse MIG/MAG 110v Welder ac dc Tig Welding Machine
-
2013 Best Quality Circuits DSP dc Inverter Welding Machine
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | ANDELI | Model Number | MIG350,MIG500 | |
| Arc Current | 350A,500A | Pulse Frequency | 50HZ | |
| Pilot Arc Current | 25A,46A | Rated Duty Cycle | 60% | |
| Motor Type | Other | Dimensions | 660x297x548MM | |
| Usage | Welding Steel, Stainless Steel, alloy, copper and etc | Voltage | three phase AC380±10% | |
| Power(W) | 14.4KVA,25KVA | Certification | CE,CCC,ISO9001 | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Factory Sale Full digital Automatic double pulse multiprocess MIG MAG Welder MIG Welding Machine MIG-350P 350AMP
Application:
1. MIG/MAG,P-MIG/MAG,DOUBLE P-MIG,CO2,TIG,P-TIG,MMA,carbon arc gouging
2. DSP control system,more accurate welding process and stable arc
3. DSP control wire feed,feeding wire more acuurately and smoothly
4. Preprogrammed expert database,intelligentize parameters combination
5. One knob synergic operation,simple and easy for everyone to use
6. Up to 100 user defned programs can be saved
7. Special 4T function is suitable for metals of good heat conductivity,perfect starts and fnishes to all welds
8. Reserved interfaces to connect with welding robot and different variants
9. Soft switch inverter technology leads to unbeatable long term reliability and very energy effcient
10. Could equip digital welding torch, quicker and more convenient
Specification:
| DSP Double Pulse MIG/MAG Welding Machine | ||
| Model | Pulse MIG-350 | Pulse MIG-500 |
| Type | IGBT Module | |
| Rated input voltage (V) | three phase AC380 ±10% / 50Hz | |
| Rated input capacity (KVA) | 14.4 | 25 |
| Rated input current (A) | 25 | 46 |
| Rated duty cycle (%) | 60 | 60 |
| Output current adjustment (A) | 25-350 | 25-500 |
| Output voltage adjustment (V) | 14-40 | 14-50 |
| Open-circuit voltage (V) | 96 | 98 |
| Efficiency (%) | ≥89 | |
| Power factor | ≥0.87 | |
| Diameter of welding wire (mm) | 0.8, 1.0, 1.2, 1.6 | |
| Net weight (KG) | 42.5 | 52.5 |
| Dimension of machine (mm) | 645×335×576 | 645×335×576 |
| Flow rate of shielded gas (L/min) | 15-20 | |
| Insulation of main transformer | H | |
| Insulation of output reactor | B | |
| including accessories: earth clamp×1pcs, cable joint×3pcs, grounding cable×3meters, control cable×5meters, pressure regulator×1pcs, water cooled MIG torch×1pcs, water tank×1set, wire feeder×1set | ||
| (P)MIG-350/500: each parts (wire feeder & main machine & water tank) are separated | ||
| (P)MIG-350H/500H: all parts (wire feeder & main machine & water tank) could be assembled together on a composite car | ||
Our Competive
More Information:
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY ANDELI.
* FULL SERVICE AND PARTS BACK UP.
* 24 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate on the device..
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
Thanks for your view ,welcome to visit our website:
Pls contact with me:Name:Jeason
Tel: +86 0577 61722822/+8613587455638
Skype:lakejeason
