Cool Fashion !! TIG 315P 380Volt High Frequency IGBT Inverter AC/DC Pulse TIG/MMA Welding Machine
- Ningbo/Shanghai China
- T/T Credit Card
You May Like
-
Factory Price Inverter IGBT AC DC TIG 315 PULSE Aluminum Welding Machines
-
2016 Wholsale New Design IGBT ac dc tig 200p welding machine,ac dc inverter tig welding machine,110v welder ac dc tig welder
-
2016 Wholsale New Design IGBT ac dc tig welding machine,ac dc inverter tig mma pulse welding machine,ac dc argon welding machine
-
2016 Wholsale New Design IGBT high frequency ac dc tig welding machine 170-210A
-
2014 Wholsale New Design IGBTac/dc pulsed tig welding machine,igbt inverter ac/dc pulse tig/mma welding machine(adc-200)
-
Promotion!! EXCLUSIVE DESIGN IGBT AC DC ALUMINUM WELDING MACHINE mma/tig/pulse welders TIG-200
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | ANDELI Or OEM | Model Number | TIG-315AC/DC | |
| Arc Current | 10-280A | Pulse Frequency | 50/60HZ | |
| Pilot Arc Current | 11.4A | Rated Duty Cycle | 60% | |
| Motor Type | Other, AC/DC Motor | Dimensions | 640x400x510MM | |
| Usage | Welds stainless steel, carbon steel, copper, aluminums and titaniums | Voltage | three phase 380V±15% | |
| Certification | CE | Warranty | 2 Years | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Cool Fashion !! TIG 315P 380Volt High Frequency IGBT Inverter AC/DC Pulse TIG/MMA Welding Machine
| Why choose us? |
1. 20 years - Andeli Group Co.,Ltd is founded in 1993. |
Application:
1. IGBT high frequency soft switch transform,high effciency and reliability
2. MCU controlled technology,multi-function in one machine,convenient to use
3. Foot pedal to control current is optional
4. Passive power factor correction makes power factor higher
5. Easy to arc starting,stable arc,high performance
6. Accurate adjustment can achieve great penetration,aesthetic apperance of weling seam and low electrode consumption
Specification data:
| Inverter TIG-AC/DC Square Wave Welding Machine | |||
| Model | TIG-315AC/DC | TIG-500AC/DC | |
| Type | IGBT Module | ||
| Rated input voltage | three phase 380V±10% / 50Hz | ||
| Rated input capacity | 13KVA | 25.7KVA | |
| Rated input current | 20A | 39A | |
| Constant current | 5-315A | 20-500A | |
| Peak current | 5-315A | 20-500A | |
| Welding current for MMA | 20-315A | 20-500A | |
| Drive current for MMA | 10-200A | ||
| Base current | 5-315A | 20-500A | |
| Start arc current | 20-160A | ||
| Crater arc current | 5-315A | 20-500A | |
| Duty ratio | 1-100% | ||
| AC bias ratio | -50%~+30% | ||
| Pulse frequency | 0.2-20Hz | ||
| AC frequency | 20-200Hz | 20-100Hz | |
| Pre-flow time | 0.1-15s | ||
| Gas delay time | 0.1-15s | ||
| Current slow up time | 0.1-10s | ||
| Current decay time | 0.1-15s | ||
| Cleaning ratio | -40%~+40% | ||
| Rated duty cycle | 60% | 60% | |
| No-load voltage | 74V | 79V | |
| Efficiency | 79% | 77% | |
| Power factor | 0.95 | ||
| Net weight | 47.2KG | 75KG | |
| Insulation of main transformer | H | ||
| Insulation of output reactor | B | ||
| Note: the rated AC is defined in the condition of 50Hz. | |||
| including accessories: earth clamp×1pcs, cable joint×2pcs, grounding cable×3meters, TIG torch (air cooled QQ300)×1pcs | |||
