Best Sell High Frequency Mosfet TIG-315 AC/DC Argon TIG Welder Portable Aluminium Electric ac dc tig 315 pulse welding machine
- Ningbo/Shanghai China
- T/T Credit Card
You May Like
-
top quality multifunction tig 315p AC/DC welding machine
-
ANDELI best seller Solar automatic variable light welding helmet/argon arc welding mask
-
ARC mig mag co2 welding machine parts
-
ADL-2000 Series Cheap Solar automatic variable light welding helmet/argon arc welding mask/welding mask/three color option
-
New Arrival Auto darkening Solar Custom Welding Helmet,Custom Welding Helmet
-
Auto darkening Welding Helmet air with respirator
Product Details
Condition | New | Place of Origin | Zhejiang, China | |
Brand Name | ANDELI Or OEM | Model Number | TIG-315AC/DC | |
Arc Current | 10-280A | Pulse Frequency | 50/60HZ | |
Pilot Arc Current | 11.4A | Rated Duty Cycle | 60% | |
Motor Type | Other, AC/DC Motor | Dimensions | 640x400x510MM | |
Usage | Welds stainless steel, carbon steel, copper, aluminums and titaniums | Voltage | three phase 380V±15% | |
Certification | CE | Warranty | 2 Years | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Best Sell High Frequency Mosfet TIG-315 AC/DC Argon TIG Welder Portable Aluminium Electric ac dc tig 315 pulse welding machine
Why choose us? |
1. 20 years - Andeli Group Co.,Ltd is founded in 1993. |
INVERTER TIG-AC/DC SQUARE WAVE
WELDING MACHINE
- Current range from 160A to 630A, to meet all kinds of different needs
- MCU controlled technology, multi-function in one machine, convenient to use
- Easy to arc starting, stable arc, high performance
Application:
1. IGBT high frequency soft switch transform,high effciency and reliability
2. MCU controlled technology,multi-function in one machine,convenient to use
3. Foot pedal to control current is optional
4. Passive power factor correction makes power factor higher
5. Easy to arc starting,stable arc,high performance
6. Accurate adjustment can achieve great penetration,aesthetic apperance of weling seam and low electrode consumption
Specification data:
Inverter TIG-AC/DC Square Wave Welding Machine | |||
Model | TIG-200AC/DC | TIG-250AC/DC | TIG-315AC/DC |
Type | MOSFET | ||
Rated input voltage (V) | single phase 220V±15% | three phase 380V±15% | |
Rated frequency (Hz) | 50/60 | ||
Rated input current (A) | 24 | 9.6 | 11.4 |
No-load voltage (V) | 56 | 45 | 45 |
Output current (A) | 10-160 | 10-250 | 10-280 |
Pre-flow time (s) | 0-2 | ||
Gas delay time (s) | 2-10 | ||
Duty ratio | 20%-80% | ||
Decay time (s) | 0-5 | ||
Duty cycle (%) | 60 | ||
No-load loss (W) | 60 | ||
Arc starting | high frequency arc starting | ||
Efficiency (%) | 85 | ||
Power factor | 0.93 | ||
Insulation grade | F | ||
Protection grade | IP21 | ||
Net weight (KG) | 23.4 | 31.2 | 31.2 |
Dimension of packing (mm) | 640×400×510 | 640×400×510 | 640×400×510 |
including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, TIG torch×1set (air cooled WP-26 for TIG-200AC/DC & TIG-250AC/DC; water cooled WP-18 for TIG-315AC/DC) |
Our Competive:
Accessories:
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY ANDELI.
* FULL SERVICE AND PARTS BACK UP.
* 24 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate on the device.We do producing many different other series welding machines,if you feel interests,please send us an inquiry!
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
