Home > Products > Temperature instrument > stainless steel biemeter temperature gauge
stainless steel biemeter temperature gauge
US$ 30 - 500
/ Piece
1 Piece(Min. Order)
- shanghai jiangsu
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | CEPAI | |
| Model Number | WSSserials | Usage | Industrial | |
| Theory | Temperature Transmitter | Accuracy | 1.5 | |
| Temperature Range | 0-500℃ |
Product Description
Product Description
Temperature range: 60-500 ℃
Accuracy: 1.5. Contactor action error limit is 1.5tiims of readings basic error. .
Thermometer dial diameter: 60, 100, 150 mm.
Tube length: 75-2000mm.
Tube diameter: 6, 8, 10 (when tube length is 100-1250); 12 (when tube length is 1250-2000mm).
Install thread: M16X1.5, M27X2, G1/2, G3/4, tube and fixed bolt joint are1 cr18ni9ti stainless steel, pressure 6.4 MPa.
Waterproof performance: the shell can withstand spray from 25mm-faucet 5m away (water pressure is not less than 2Kg/m²), no water penetrate the thermometer case within 5minitues.
Housing: IP65
Contact rated power: 10 VA
Contact maximum operating voltage: ~ 380 v or 220 v
Contact maximum working current: 1 a (non-inductive load)
Working voltage should be between 15V and 48V.
Accuracy: 1.5. Contactor action error limit is 1.5tiims of readings basic error. .
Thermometer dial diameter: 60, 100, 150 mm.
Tube length: 75-2000mm.
Tube diameter: 6, 8, 10 (when tube length is 100-1250); 12 (when tube length is 1250-2000mm).
Install thread: M16X1.5, M27X2, G1/2, G3/4, tube and fixed bolt joint are1 cr18ni9ti stainless steel, pressure 6.4 MPa.
Waterproof performance: the shell can withstand spray from 25mm-faucet 5m away (water pressure is not less than 2Kg/m²), no water penetrate the thermometer case within 5minitues.
Housing: IP65
Contact rated power: 10 VA
Contact maximum operating voltage: ~ 380 v or 220 v
Contact maximum working current: 1 a (non-inductive load)
Working voltage should be between 15V and 48V.
