12V 20A 24v 10a 48V 5A power supply 240W CE RoHS approved

FOB Price

Negotiable / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

power supply 24v 240w
1.Output low ripple and noise
2.The most thiner structure
3.Two years warranty
4.CE&ROH

power supply 24v 240w

· built-in EMI filter

· 100% load test

· Full range of input voltage

· output voltage accurate and stable

· Output over-voltage, over-current and short-circuit protection

· Output low ripple and noise

· Two year warranty

· Average working no trouble >50,000 hours

Product Electric Parameters
Input specification	Input voltage			AC90V---264V
	Input frequency			47-63Hz
	Input surge			20A@120VAC 40A@230VAC
Output specification	Output voltage can be adjusted			±10%
	Start-up time			<=1S(input230V,Io=100%)
	keep time			>=20mS (input230V,Io=100%)
	Voltage regulation			(Full load) <=0.5%
Protection function	Overload protection			105% - 150% rated power, automatic recovery
	Over-voltage protection			105% - 150% of the rated voltage
Insulation intensity	Input---output			1500VAC/1min
	Input---ground			1500VAC/1min
	Input---ground			500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards	According with GB9254, EN55022 class A EN61347-2-13:2008 standards
Environmental	working temperature			- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature			- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level			<=2000M
Structure	Size(mm)			200(L)110(W)50(H)
Cooling method	Cooling method			Through the fan make temperature decrease
Weight	0.7KG/PCS
Product Type Table
Product model		output specification			ripple, noise	efficiency
S-250-12		12V	20.83A		100mV	80%
S-250-24		24V	10.41A		100mV	80%
S-250-48		48V	5.20A		240mV	82%
