Product Details
| Place of Origin | Jiangsu, China | Brand Name | R&X | |
| Model Number | Hyacinth-100 | Type | Wind Power Generator |
Product Description
Specifications
wind generator motor1.Start in breeze 3.0m/s
2.Spinning then charging
3.High efficient output.
4.CE,ROHS,ISO9001
Wind generator motor 100W. Combine with wind/solar hybrid controller(LCD display)+off gird inverter.
Sample Purchase online:Click here
Please leave a message about whether you need
12V or 24V.
Introduction
1. Which is using ultra-light composite materials and engineering
plastics.
2. The headpiece can be arbitrary rotated with anti-winding ability and automatically turned
protection when faced with strong winds.
3. As high efficiency, they can be made hybrids system with solar panel.
Technical Data
Model | Hyacinth-100 |
Rated Power | 100W |
Rated Voltage | DC/AC 12V/24V |
Rated Current | 8.8A/4.4A |
Rated Speedy | 860r/m |
Max Power | 115W |
Number of blade | 3 PCS |
Start-up wind speed | 3m/s |
Cut-in wind speed | 3.5m/s |
Cut-out wind speed | 15m/s |
Security wind speed | 45m/s |
Rated wind speed | 12m/s |
Engine | Three- phase permanent magnet generator |
Rotor diameter | 1050mm |
Blade material | Carbon fiber reinforced plastics |
Output line anti-winding device | Overall three-phase commutator |
Over-speed wind protection | Tip stall protection + turned protection + Electromagnetic brake |
Life span | 10years |
Equipment surface protection | Aluminum oxide+plastic coating |
Working temperature | -40°C to 70°C |
N.W. | 2.8kg |
Packing material | Carton box and foam material |
packing dimension | 63cm*28cm*25cm |
G.W. | 3.5kg |
Controller*Inverter | 300W |
Drawing | |
100W monthly power generation curve | |
Powe curve | |
Certification |
Description
1.simple structure,running stably,power supply for city lamp,monitoring and home.
2. Small size and flexibility,lively Colors,beautiful curve,low noise and environmental harmony.
3. Anti-Rust,Anti-Corruption Damp-Proof,Water-Proof,Stand-Proof.
4. Brand New in box
5. CE Certificate
6. ISO9001:2000 Quality Certification
7. ROHS Certification
8. Large power, low volume, high efficiency
9. High efficiency of anti-wind ability,move mutely and steadily
10. Blades with the ability of automatically stall protection under strong wind
11. 3 years free warranty
Picture of controller
Picture of inverter
Socket design for different country
Application
