huaxia high quality backhoe attachment compact tractor

backhoe attachment compact tractor

1,free tool box and free easy damage parts.

2, warranty time is 12 months after the goods delivery your port.

3,delivery time is 20 days for one container.

4.10 units in one 20ft container.40units in one 40ft container.

5.every color we can do for you.

6.we can do the tractor with your logo in your order.(It Is Free)

7.we can find a good shipping company for you.

8. Our business model is both wholesale and retail, so our MOQ is one piece.

9.payment term is T/T30% in advance ,70% T/T after the shipping, or L/C at sight.

554 specifications

Whole machine Brand / HUAXIA

model / 554

type / 4×4

size mm 3790×1625×2100

Wheel base mm 2010

Wheel distance mm 1260/1250-1350

Wheel distance adjustment model / Not adjust

Min ground clearance mm 320

Min operating weight kg 2160

Front shaft weight / rear shaft weight kg 970/1190

counterbalance weight ,( front / rear ) kg 130/110

shift(forward/back/crawl) / 8/2

Engine with clutch connection Method . / Direct connection

Start model / Electrical

Engine Brand / Jiangdong

Model / Vertical,3 cylinder,water-cooled,4 - stroke

Type / JD4102T

Factory / Jiangsujianghuai engine factory

Inspiration type / Nature inspiration

NO of cylinder cylinder 4

Bore ×stroke mm 102×105

Displacement L 3.432

Compression ratio / 17:1

Power kW 40.5

Speed r/min 2300

Fuel injection pump Model / Direct model BH4QT90R9

fuel spray nozzle model / Long model with hole PF68S19

Air filter model / KM160-07100-01

Starter model / QDJ152TD

Cooler model / Water cooled

Front light model / 45/40W

Diesel tank type / HY50012

Working pressure kPa 1.6

capacity L 41.3

Noise silencer

Noise silencer size( length*width*height) mm 125*520

Noise silencer Weight kg 3.9kg

Steering and brake Steering system / Hydraulic

Brake system / Shoe type

transmission Clutch type / Single sheet,dry,combined with double usage

Gearbox type / Two shaft,(4+1)×2composition

Gear shift / sliding sleeve shift

Center transmission type / Spiral bevel gear

Differential mechanism / Close,two planetary bevel gear

Final transmission type / planetary reduction gear

Running system Frame model / No frame

Tyre( front / back ) / 8.3-20/12.4-28

Tyrepressure (frant / back) kPa 80-120/80-120

All of the goods produce by the order.

The dlivery time is 20 days for one 20ft container.30 days for one 40ft container

10 units in one 20ft container
