Universal farm tractor

FOB Price

US$ 5,000 - 9,000 / Unit

2 Units(Min. Order)

Port Qingdao Or Others
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	36.8kw
Certificate	CE	Brand Name	HUAXIA
Model Number	JX504	Place of Origin	Shandong, China
After-sales Service Provided	Overseas third-party support available

Product Description

1,free tool box and free easy damage parts.

2, warranty time is 12 months after the goods delivery your port.

3,delivery time is 20 days for one container.

4.10 units in one 20ft container.40units in one 40ft container.

5.every color we can do for you.

6.we can do the tractor with your logo in your order.(It Is Free)

7.we can find a good shipping company for you.

8. Our business model is both wholesale and retail, so our MOQ is one piece.

9.payment term is T/T30% in advance ,70% T/T after the shipping, or L/C at sight.

MODEL	UNITS	400	404	450	454	480	484
ractor typrtytyepe e		40HP,4X2	40HP,4X4	45HP,4X2	45HP,4X4	48HP,4X2	48HP,4X4
ENGINE Model		4 cylinder Chinese Brand diesel Engine
Model		JD490		JD495
Rated power	KW	29.4	29.4	33.1	33.1	35.3	35.3
Rated speed	R/Min	2400	2400	2200	2200	2400	2400
No. of cylinders		4	4	4	4	4	4
Max. Exhaust gas temperature	°C	≤600	≤600	≤600	≤600	≤600	≤600
TYPE		In-line,water cooled,4-stroke,natural aspirated
Aspiration		natural aspirated
Spark in sequence		1-3-4-2
Bore/Stroke	Mm	93mm*105mm		95mm*105mm		95mm*105mm
Displacement	L	2.853		2.977		2.977
Max torque operation	N.m	≥146.80		≥165.10		≥168.50
Fuel consumption	g/kw.h	≤245
oil consumption	g/kw.h	≤2.04
oil pressure	Kpa	Normal working: 200-500. Idle speed working :≥80
CLUTCH		10 inch, dry-type, two-stage
TRANSMISSION
Gear box		2 axis 4X(2+1) gear group type
Shifting		meshing sleeve gear shifting
Differential Gears		Double planet wheels, closed type
Differential lock		Pin type
Final transmission		Planet wheel type
PTO SHAFT
Type		Independent and synchronous P.T.O.
Speeds	R/min	540/760 or 540/1000 or 760/1000
Spine shaft shape		6 GEARS RECTANGLE SPLINE
HYDRAULICS
Three point linkage		Category II
Hydraulic output adaptor		Size: M16X1.5, quantity: 1; output flow rate: 20L/min
OTHER
Front Driving axle		For 4X2WD, inverted U pipe balancing type, for4X4WD, bevel gear reducer tri-section separable type axle housing
Full tank volume	L	42
Cooling water volume	L	9
Power take-off shaft type		Half Independent
Front axle ballast	kg	112	140	112	140	112	140
Rear axle ballast	kg	100	200	100	200	200	300
DIMENSIONS
Length(With front ballast)	mm	3835	3835	3835	3835	3835	3835
Width	mm	1620	1620	1620	1620	1620	1620
Height (to the exhaust vent )	mm	2135	2210	2135	2210	2135	2210
Front Wheel base	mm	For 4x2WD:1200-1500,Normal 1300; For 4x4WD, 1280
Rear Wheel base	mm	1200-1500 Normal 1300
Min. Ground clearance	mm	410	325	410	325	410	325
Applicable ground clearance	mm	450	375	450	375	450	375
Axle base	mm	1910	2030	1910	2030	1910	2030
Standard front tyres		6.00-16	8.3-20	6.00-16	8.3-20	6.00-16	8.3-20
Standard rear tyres		12.4-28	12.4-28	12.4-28	12.4-28	12.4-28	12.4-28
Weight	Kg	1665	1890	1665	1890	1734	1952
OPTIONAL

All of the goods produce by the order.

The dlivery time is 20 days for one 20ft container.30 days for one 40ft container

10 units in one 20ft container

1. Test our quality before you making decision, pls visit our samplesolution page to get more help

2. If your order quanti our MOQ requirement, pls CONTACT US to get better price

3:For more details,pls email us or visit our website,we'll be gald to repy you here without dela

FAQ

(1). Manufacturer or Trading Company

We are a leading tractor manufacturer for 14 years, and specialize in 12-150Hp tractors in China.

(2). MOQ

1 unit

(3). Spare Parts

Free toolbox and easy wear parts.

(4). Shippment

We can help you arrange shippment.

(5). Delivery Time

Usually 25 days

(6). Warranty Time

Complete service system, 18 months since arrival of destination port

(7). Payment Terms

We accept 30%T/T in advance, and 70% T/T after shipping or L/C at sight.

(8). Tractor Options

Can be equipped with ROPS, Canopy, Cabin, AC Cabin, Air Brakes, Hydraulic Valve Out, Paddy Tire, Turf Tire or as per your requirements.

(9). Tractor Logo

We have our own logo. And we also can make your own logo in your order for free.

(10). Package and Loading qty

1.Nude Package: 3 complete units/40GP, 3 complete units with Cabin/40HQ

2.SKD Iron Frame Package: 8 units/40HQ

(11). Tractor Implements

Loader, Mower, Plough, Trailer, Slasher, Snow Blower or as per your requirements.

(12). Part supply

Complete Parts Workshop, and can supply all parts, pic as below
