Home > Products > Delshine Pumps > DBY Electrical Diaphragm Oil Pump

DBY Electrical Diaphragm Oil Pump

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port ShangHai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	D&S
Model Number	DBY	Theory	Other, Electrical diaphragm Pump
Structure	Diaphragm Pump	Usage	Other, Petroleum,chemical,ceramic,metallurgy industrials etc.
Power	Other, Electric, 0.55-5.5KW	Standard or Nonstandard	Standard
Fuel	Other	Pressure	Low Pressure
Application	Other, Petroleum,chemical,ceramic,metallurgy industrials etc.

Product Description

Specifications

1.Capacity:0.5m3/h-20m3/h
2.Head:30m
3.Self priming ability(m):7m
4.Suction(m):3-5m
5.Power:0.55-5.5KW

Capacity:0.5m3/h-20m3/h
Head:30m
Self priming ability(m):7m
Suction(m):3-5m
The max particles passed(mm):1-10mm
Speed:1450r/min
Power:0.55-5.5KW
N.W (kg):50-610KG
Caliber(inch):1"-4"thread

Summary:

DBY pump is the lastest design,that can be instead f centrifugal pump and screw pump in almost every way!

The pump is copy of USA ABEL company, operated at low pressure, below 3 bar.

Application:

1) Kinds of poisonous,flammable,volatile liquild,

2) Srrong acid, alkali, corrosive liquild.

3) High tempreature media, up to 150°C.

4) Increase pressure for filter press.

5) hot water recycle and circulation.

6) delivery oil for oil tank truck, Oil strrage.

7) Suck pickled vegetables, sauce, mashes potato, chocolate, etc.

8) Paint, gum, adhesive

9) Mud slurry, cement, mortar

10)Clearance sewage and balance oil for tanker, barge

11)Rubber slurry, organic solvenr, stuffing.

12)Beer, syrup, ferment food slurry

13)Other special media

Type	Flow (m3/h)	Suction (m)	Head (m)	Pressure kgf/cm2	Power rev/Kw	Temperature(°C)		Inlet Diameter	weight (kg)
Type	Flow (m3/h)	Suction (m)	Head (m)	Pressure kgf/cm2	Power rev/Kw	CA	SA	Inlet Diameter	weight (kg)
DBY10	0.5	3	30	3	1450/0.55	90	150	Thread 3/8IN	50
DBY15	0.75	3	30	3	1450/0.55	90	150	Thread 1/2	50
DBY25	3.5	4	30	3	1450/1.5	90	150	Thread 1	170
DBY40	4.5	4	30	3	1450/2.2	90	150	Thread11/2	180
DBY50	6.5	4.5	30	3	1450/4	90	150	Flange50mm	400
DBY65	8	4.5	30	3	1450/4	90	150	Flange65mm	400
DBY80	16	5	30	3		90	150	Flange80mm	900
DBY100	20	5	30	3		90	150	Flange100mm	1000
