CRS-4000 Common Rail System Tester
- BEIJING TIANJIN FUJIAN SHANGHAI GUANGZHOU qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | INJECTRONIX | |
| Model Number | CRS-4000 | Power | Electronic | |
| Usage | Auto Testing Machine |
Product Description
CRS-4000 common rail system tester:
Features:
CR Injector Drivers
6 solenoid injectors
High voltage for Bosch, Denso injectors
Low voltage for Delphi injectors
6 piezoelectric injectors, made by Siemens and Bosch (optional module)
Short circuit protection for both solenoid and piezo injector drivers
CRS-4000 Applications
CR Pump Drivers
Multiple independent PWM (Pulse Width Modulation) output channels to drive pump solenoids
Testing pumps with single regulation valve
Bosch CP1/CP2/CP3
Delphi CRSP
Denso HP3/HP4
Testing Siemens DCP pump with two regulation valves
Drive 3 DRVs for testing pump capability
2 special output channels synchronous with pump speed to drive the two control solenoids on Denso HP0 (ECD-U2)pump (optional module)
Fuel Rail Pressure Sensor
Pre-calibrated data for Bosch, Delphi, Denso pressure sensors
Automatic (close-loop)rail pressure control
Software based over-pressure protection
User Interface
Small key pad
Large LCD screen
Others
One year manufacture warranty
Injector and pump test procedure and database, off-line
DRV adaptor for pump flow rate test (Optional)
Rich accessories
