Common Rail Injector Test Bench for Solenoid and Piezo Injectors
- beijing
- Credit Card PayPal
You May Like
Product Details
| Brand Name | injectronix | Model Number | CRB100 | |
| Usage | Auto Testing Machine |
Product Description
Specifications
CRB-100 is designed to test one common rail injector with either solenoid or piezoelectric technologies. It integratesan ultrasoCommon rail injector test bench CRB-100 is designed to test one common rail injector with either solenoid or piezoelectric technologies. The test bench integrates an ultrasonic cleaner for cleaning the sophisticated injector components.
Function: |
Measuring fuel delivery of a common rail injector |
Specification
Using pneumatic amplifier actuator to generate high pressure fuel
source to feed the injector
a)a) Required shop compressed air supply, 6-8bar,out flow
a) a)150L/min
a)b) Fuel Pressure range 0-1200bar
a)c) Fuel type: diesel fuel
a)d) Fuel Pressure stability +/-50bar
Simulate engine ECU signals to drive either a solenoid or a
piezoelectric actuator in a common rail injector
a)a) Adjustable injection frequency, represented by engine
a) a)speed, 0-4000rpm
a)b) Adjustable injection pulse width or injection duration,
a)a)0-6ms
Fuel delivery measurement
a)a) Injection counter set: 0-9999 injections
a)b) Fuel delivery measured by glass graduates, for both fuel
a)a)injection and injector leakage
Fuel filtration: 5µm
Integrated ultrasonic cleaner
a)a) Power: 360W
a)b) Basin dimension(mm): 300×240×150
Main AC power, single phase, 500W, 220V/50Hz, or 115V/60Hz,
or per customer specification
Test bench base dimension(mm): 1550×850×650
Test bench weight: 250kg
Rich accessories
