HS75 Sand Blender
- Shanghai
You May Like
Product Details
| Place of Origin | Hubei, China | Brand Name | Petrokh | |
| Model Number | HS75 Sand Blender |
Product Description
Specifications
It is fully hydraulically driven. Four sets of oil pumps are powered by the deck engine through a transfer case 1.It is a unitized equipment for heavy duty fracturing Operations. Full hydraulic driving. The power of operating parts comes from deck and chassis engine, and installed power is up to 500HP.
2. High displacement: one blender is enough for heavy duty fracturing operation.
3.It can be equipped with many automatic control system, including liquid level control, density control, liquid additive control, dry additive control and discharge control system. Data acquisition, feedback and programmable control operations can all easily be realized.
Main Parameters
| Model | HS75 |
| Max displacement of sand pump bbl(m3/min) (Water) | 75(12) |
| Max. working pressure psi(MPa) | 70(0.5) |
| Max feeding capacity of sand feeder gpm(kg/min) | 16440(7456) |
| Displacement of three liquid additive systems gpm(L/min) | 10(37.8) 53(200) 90(340) |
| Displacement of dry additive system gpm(L/min) | 27(102) |
| Volume of blending tank bbl(m3) | 9.4(1.5) |
| Overall dimensions in.(mm) | 441×99×158(11207×2500×4000) |
| Total weight lb(kg) | 55115(25000 |
