55 gallon steel drum production line or steel barrel production line for keeping petrol or bitumen
- 60 Set / Sets per Month
- Dalian
- T/T L/C D/P D/A
You May Like
-
200-216.5L steel drum production line or steel barrel production line for keeping petrol or bitumen
-
200L-216.5L steel barrel line for keeping petrol or bitumen
-
PR-10T Decoiler Or 200L steel drum production line
-
PRO steel drum production line or steel barrel production line for keeping petrol or bitumen
-
200L-216.5L steel drum production line or steel barrel production line (Rear section)
-
2014 supplier 55 gallon(216.5L) steel drum production line
Product Details
| Condition | New | Application | Food, Commodity, Medical, Chemical | |
| Packaging Type | Cartons | Packaging Material | Wood | |
| Automatic Grade | Semi-Automatic | Driven Type | Hydraulic | |
| Voltage | 380V/50HZ/3PHRASE | Power | 150KVA | |
| Place of Origin | Liaoning, China | Dimension(L*W*H) | 3700x700x1600(mm) | |
| Weight | 5T | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Applied sheet :SPCC steel plate or cold-rolled sheet2.Drum Inner diameter:571.5mm
3.Drum Outside diameter:585mm
55 gallon steel drum production line or steel barrel production line for keeping petrol or bitumen
Short introduction:controlled by PLC,hydraulic drive |
Main technics: a)Beading height:≤14mm b)Drum height:894-905(mm) c)Hydraulic system pressure:8Mpa d)Air pressure:0.1Mpa e)Machine size:3700x700x1600(mm), |
- Steel-drum production line (5pcs/min)
Features: This series of drum-production equipment is designed and developed on the basis of domestic mature models. It is easy to operate and maintenance cost is low.
Applicable manufacturer: This series of equipment is suitable for medium and small-scaled drum-production enterprise or chemical, food and drinks plants with annual consumption 100,000~600,000 pieces of drums.
- Workshop Plan
Workshop Height: ≥6 M
- Workshop Foundation and Related Accessory Establishment
1. Water: Recycled cooling water. Water entrance temperature<32oC, Water out temperature<40oC,
Pressure: 0.1-0.45Mpa,runoff :20m3/h.2" Self-Suction pump:1unit.
2. Power:Voltage 380V,Frequency:50Hz
3. Transformer Capacity≥650KVA
4. Water Consumption:0.2Kg/Pc
5. Air Compressor:Pressure: 0.6Mpa,runoff: 10m3/min.
6. Gas Storage Tank:4 pcs,Capacity:0.6 M /Unit Pressure:1MPa
- Technical Specification of Equipment
Conveying Way:Step-advancing shift conveyor
Production Line Control Method:Automatic or Manual, multi machines or single machine working method.
