Seam-welding machine for 55 gallon steel drum production line

FOB Price

USD $20,000 - $100,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Food, Commodity, Medical, Chemical
Packaging Type	Cartons	Packaging Material	Wood
Automatic Grade	Semi-Automatic	Driven Type	Hydraulic
Voltage	380V/50HZ/3PHRASE	Power	150KVA
Place of Origin	Liaoning, China	Dimension(LWH)	3700x700x1600(mm)
Weight	5T	After-sales Service Provided	Engineers available to service machinery overseas

1. Beading height:less 14mm
2. Drum height:894-905(mm)
3. Hydraulic system pressure:8Mpa
4. Air pressure:0.1Mpa

Seam-welding machine for 55 gallon steel drum production line

NO.	Basic parameters	Parameter value
1	Input power supply of control cabinet	Three phase 380V 50HZ
2	Rated input capacity	250KVA
3	Primary voltage of transformer	380V
4	Secondary voltage of transformer	6.5V
5	Persistency rate of rated load	50%
6	Rated pressure of pneumatic system	0.6MPa
7	Gas consumption	0.5M3/h
8	Maximum thickness of welding board	1.5+1.5mm
9	Maximum voltage of electrode	5000 N
10	Operating stroke of lower electrode	20~60 (can be designed according to the customer’s need)
11	Operating stroke of upper electrode	Fixed
12	Sheet	Cold-rolled sheetσb<450Mpa
13	Diameter of drum	φ450---φ600mm
14	Amount of overlap of welding	2.5±0.5mm
15	Size of steel drum before welding	Width of panel (length /height of drum) ±0.5mm Length of panel (diameter of drum) ±0.5mm Diagonal≤1.0
16	Welding length	500--1100mm
17	Production speed	420—480 pieces/hour
18	Cooling water	The pressure should not be lower than 0.2MPa, The maximum inlet temperature is 30℃ Flow rate 30L/min
