Home > Products > Industrial Valves > Stainless Steel Butt Welded 3pc Ball Valve
Stainless Steel Butt Welded 3pc Ball Valve
- 100000 Piece / Pieces per Month
- Any port of China
- T/T Credit Card
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Medium Pressure | Power | Manual | |
| Material | Stainless Steel | Temperature of Media | Medium Temperature | |
| Media | Other, water, oil, gas, etc. | Port Size | 1/4"~4" | |
| Place of Origin | Chongqing, China | Model Number | Q11F | |
| Brand Name | Hi-Sea | Application | General |
Product Description
3pc Ball Valve
Stainless Steel Butt Welded 3pc Ball Valve
1) Size: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3"
2) Material: WCB, 304, 316 (CF8,CF8M)
3) Applicable Temperature: -20~232~350°C
4) Applicable Medium: Water, Oil, Gas, Non-corrosive Liquids
5) Threaded end: NPT, BSPT, BSP, DIN259/2999 Full Bore
6) Operation: Manual
7) Locking device (option)
Mimension:
SIZE | 1/4” | 3/8” | 1/2” | 3/4” | 1” | 11/4” | 11/2” | 2” |
D | 11.6 | 12.7 | 15 | 20 | 25 | 32 | 38 | 50 |
L | 60 | 60 | 70 | 85 | 95 | 110 | 130 | 150 |
H | 50 | 50 | 60 | 64 | 71 | 78 | 86 | 95 |
E | 100 | 100 | 130 | 130 | 165 | 165 | 190 | 190 |
C | 14 | 17.5 | 22.7 | 27.5 | 33.5 | 42 | 48.6 | 60.5 |
Material List:
NO. | PART NAME | MATERIAL | ||
STAINLESS STEEL | CARBON STEEL | |||
1 | BODY | CF8 | CF8M | WCB |
2 | JOINT RING | PTFE | PTFE | PTFE |
3 | CAP | CF8 | CF8M | WCB |
4 | BALL | SS316 | SS316 | SS304 |
5 | STEM | SS304 | SS316 | SS316 |
6 | NUT | SS304 | SS304 | SS304 |
7 | WASHER | SS304 | SS304 | SS304 |
8 | HANDLE COVER | PLASTIC | PLASTIC | PLASTIC |
9 | HANDLE | SS304 | SS304 | SS304 |
10 | STEM NUT | SS304 | SS304 | SS304 |
11 | STEM WASHER | SS304 | SS304 | SS304 |
12 | GLAND NUT | SS304 | SS304 | SS304 |
13 | STEM PACKING | PTFE | PTFE | PTFE |
14 | THRUST WASHER | PTFE | PTFE | PTFE |
15 | JOINT GASKET | PTFE | PTFE | PTFE |
16 | BOLT | SS304 | SS304 | SS304 |
Standard Export Packing:
Modern Workshop:
Contact Us
- Chongqing Hi-Sea Marine Equipment Import & Export Co., Ltd.
- Contact nameJun Xie Chat Now
- Phone86-23-67956606
- Address15-1, Jinshan Matrix A, Saidi Road
