Product Details
| Place of Origin | Guangdong, China | Brand Name | Jemis | |
| Model Number | JM-1704 |
Product Description
China leader factory 15dBi people/asset/vehicle management Ethernet 2.4g active long range rfid reader 100m
Features:
Small size, easy to install
Long distance identification, strong receiving sensitivity
Excellent anti-collision performance
Little RF Power (No more than 1dBm, transmitting power≤2mw), which is suitable for human carry and environment friendly.
Multiple communication interfaces, also can be customized
Self-development communication protocol and can customize and expand as your requirement
Compatible to other tag protocol and improve the performance of system application
Specifications:
Product Parameter | Parameter Description |
Frequency Range | 2.4GHz~2.5GHz |
Identify direction | Directional |
Identify speed | More than 100tags/seconds |
Antenna | Built-in 15dBi antenna |
Receiving sensitivity | -90.0dBm |
Operating Method | FHSS or fixed frequency(setted by software) |
Reading distance | 0~100m adjustable (RSSI reader can be adjusted less than 10m) |
Anti-collision | Up to 200 tags read simultaneously |
Buffer capacity | 2000 tags data |
Communication speed | 25Kbps, 1Mbps, 2Mbps(adjustable) |
Communication interface | RS-232, RS-485, Ethernet, Wiegand26/34 |
Input and output | 1 triggering input, 1 relay output |
Optional function | 2 relays, CAN, RSSI, ID match function, Offline function, Time function |
Power supply | AC input: 100~240V, 50/60Hz 1.2A; DC output: 5V/1A |
Product size | 227mm*227mm*60mm |
Gross weight | 2.78kg |
Net weight | 1.82kg |
Working temperature | -40°C~+80°C |
Storage temperature | -40°C~+125°C |
Working status indication | Buzzer |
Accessories | Power adapter, Power cable, RS-232 cable, Mounting bracket |
Application:
Intelligent transportation management
Asset identification, tracking and checking management
Intelligent management in traffic police, patrolman etc
Position moniter management for baby, prisoner, olders psychotic etc
Electronic ticket, access control, time attendance, school management etc
