Mini Aluminium-Plastic Blister Packing Machine
- 1 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Food | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Power | 1.5kw | Place of Origin | China | |
| Brand Name | SPM | Model Number | SLB |
Product Description
Specifications
It adopts a cycloid pin gear device for the main driving unit,which has long life and smooth running.
We can supply a complete set according to the users' requirments.
Specifications
which has long life and smooth running.
Product information:
It is suitable for automatic double-aluminum foil hot sealing package for tablets, candy and pills in medicine, healthcare, chemical, foodstuff etc industry. Meeting the requirement of sealing for avoiding light, and also it can be used in double plastic hot sealing package. It automatically completes the functions such as vibrating material feeding, broken piece filtering, counting, lengthways and transverse, indentation, cutting waste material, marking batch number etc. It adopts PLC programmable controller, with frequency converter, man-machine interface to operation, and also can adjust cutting speed and trip distance at random. It is accurate feeding, tight sealing, full purpose, stable performance, ease of operation. It can enhance the product grade, extended product durability. It is ideal equipment for pharmaceutical industry.The products are in conformity with the standards of the GMP.
Main Technical Parameters:
Specs | SLB-220 | SLB-150 | |
Speed of drum(rpm) | 7-15 (stepless) | ||
Production Capacity(ten thous pics/h) | 2-8.5 | 1.4-5 | |
Packing dimensions(mm) | 220mm | 150mm | |
Can Be Manufactured As User's Requirements | |||
Packing material specification(mm) | PVC for medicine | 0.05-0.1×220 | 0.05-0.1×150 |
AL-plastic combined film | 0.08-0.10×220 | 0.08-0.10×150 | |
Hole dia of reel | 70-75 | ||
Electro thermal power | 380V/1.5kw×2 | 380V/1.5kw×2 | |
Main motor power (kw) | 0.55 | ||
Air pressure(Mpa) | 0.4-0.6 | ||
air supply | ≥0.1m3/min | ||
Overall dimensions(mm) | 1500×750×1670(L×W×H) | ||
Weight(kg) | 650 | 650 | |
