Fully Computerized Flat Knitting Machine for Sweater

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Ningbo or Shanghai Port China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Product Type	Sweater
Type	Jacquard	Place of Origin	Zhejiang, China
Model Number	803F 1003F	Knitting Style	Flat
Knitting Method	Other, 3systems	Computerized	Yes
Weight	1200kg	Dimension(LWH)	42509301440
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specification and function:

Gauge	7G 8G 9G 10G 12G
Knitting width	80 ,100inches
Knitting speed	Controlled by servo motor with 32 sections speed optional, max1.2m/s. Serve motor will use the precise backward control and link up the high speed operation ability of digital signal processor(DSP),which control IGBT to produce the accurate output electric current.
Knitting system	single carriage with triple systems.
Knitting function	exchange needles, only hookup yarn (except for E series machine) , pick holes( like lace),intarsia, jacquard, inapparent or apparent narrowing needle , and other regular or irregular patterns
Racking	Controlled by servo motor , can move within 2inches ,and with fine adjusting function.
Detect alarm system	The safety alarm detect device, achieve to up down and left-right swing function ,which surmount the normal flat knitting machine with detect simply left-right swing only and great increase the detect protect functions.
Encode	Advanced encoder adopted
Transfer cam	The transfer cam is compose designed ,single or double or three cam system all can transfer an other cam system for knitting which will achieve to high production efficiency knit. ( F series machine and E series machine controlled by stepping motor)
Stitch density``````````````	q
Sinker system	Controlled by stepping motor, adjust according to different knitwear, assist decreasing or adding needles.
Comb device ( S series machine)	Closed U compound needle adopts the principle of activity release, which achieves the compound needle to pick up and release yarn.
Scissors & Clips ( S series machine)	Two scissors and four clips, respectively controlled by 6 motors. Program instruction can operate synchronize or separately, improve the work efficiency, reduce waste yarn
Take down roller	Programmed instruction controlled by stepping motor ,32 levels selection adjustable area is:0-100
Yarn carrier	28 yarn feeders be set at each side of 4 guide rails (E serises machine , 23 yarn feeders at each side of 3 guide rail ), can be switched at any position of neilsbed.
Protection	The machine will automatically alarm if yarn breaks, knots, floating, yarn rewind ,end of knitting ,fail of racking, needle breaks and error programming occur, also set up the safety auto-lock protect device.
Controller	1. Screen: Adopt LCD touch screen and figure interface, input device: USB storage 1G, a great amount of design files can be stored at the same time and they can be fetched out for use at any time as per production requirement.
	2. Monitoring menu: each kind of operating parameter can be shown and it can be adjust at any time when the machine is running, making conveniences for operations as much as possible.
	3. The software of design system and control system is easy to upgrade and free of charge.
	4. Multi language version: there are Chinese ,English etc. language version, the other language version set up shall according to customers requirement.
	5. Hengqiang system or the system that compatible with Japanese brand’s system can be an option.
Power	Single-phase 220V, adopt advanced CMOS technology ,having memorizing function when power off.
