Electrical-hydraulic synchronous press brake

Model: WF100T/3200

No

Name

Amount

Unit

1

Nominal pressure

1 000

KN

2

Poles distance

2 600

mm

3

Throat depth

320

mm

4

Slipper stroke

120

mm

5

Max. opening height

380

mm

6

Slipper stroke adjustment

100

mm

7

Diameter of cylinder

180

mm

8

Main motor power

7.5

kw

9

Oil pump power

25

ml/r

10

System pressure

22

Mpa

11

Wallboard thickness

40

mm

12

Slipper thickness

50

mm

13

Machine weight

6 600

Kg

14

Work bench length

3 200

mm

15

Dimension (LxWxH)

3 300x1 750x2 420

mm

No.

Name

Brand

Location

1

Motor

Dangpeng

Zhenjiang, China

2

Electrics

Schneider/OMROM

Eruopean brand

3

Oil Cylinder

Wuyang

Maanshan, China

4

Seal ring

NOK

Japan

5

Pump

Hangfa

Shanghai, China

6

Hydraulic system

Rextroth

Rexroth ,Germany

7

Two axes Controller

E200

Estun,China

8

Punch and Die

Xinming / Lianmeng

Maanshan, China

9

Pipe connector

EMB

Germany

10

Foot Switch

Karcon

South Korea

11

Ball lead screw

HIWIN

Taiwan

12

Straight-line guide

HIWIN

Taiwan

NO.

Item

Quantity

Remark

1

Control system

1set

                                   Holland  DELEM DA65W

2

Servomotor and drive

1 set

Janpanese YASKAWA

3

Hydraulic system

1 set

Gemeny HOERBIGER

4

Ball bearing lead screw

2 pieces

                                 Taiwan HIWIN

5

Straigh-line guide

2 pieces

Taiwan HIWIN

6

Connections

1 set

Gemeny EMB

7

Seal rings

1 set

Gemeny FIETZ,Janpanese VALQUA

8

Grating ruler

2 pieces

Italy GV

9

Main electrical components

1 set

TELEMECANIQUE
