Overhead OPGW Cable

FOB Price

US$ 1,000 - 2,000 / Kilometer

1 Kilometer(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	OPTELEC
Model Number	OPGW

Overhead OPGW cable

Product Description

Overhead OPGW cable

Product features:

1-Stranded design allow up to three steel tubes

2- Laser welded stainless steel tubes provide mechanical and thermal protection for optical fibers.

3-Light weight and small diameter

4-Good resistance to moisture and hydrogen ingress

Typical OPGW structure:

OPGW standard compliance

IEEE -1138, IEC60794-4-1, IEC60793, ITU-T G.652, ITU-T G.655, IEC60794-1, DL/T 788-2001, YD/T 980-2002

OPGW technical parameters:

According fiber cores, weather condition, RTS, short circuit current capacity, DC resistance, line voltage and etc.

OPGW main models:

Cable model	OPGW-60	OPGW-70	OPGW-90	OPGW-110	OPGW-130
Number /diameter(mm) of stainless steel tube	1/3.5	2/2.4	2/2.6	2/2.8	1/3.0
Number /diameter of AL wire(mm)	0/3.5	12/2.4	12/2.6	12/2.8	12/3.0
Number /diameter of ACS wire(mm)	6/3.5	5/2.4	5/2.6	5/2.8	6/3.0
Diameter of Cable (mm)	10.5	12.0	13.0	14.0	15.0
RTS(KN)	75	45	53	64	80
Cable weight (kg/km)	415	320	374	432	527
DC resistance(20⁰C W/km)	1.36	0.524	0.448	0.386	0.327
Modulus of elasticity(Gpa)	162.0	96.1	95.9	95.6	97.8
coefficient of Linear thermal expansion(1/×10^-6)	12.6	17.8	17.8	17.8	17.2
Short circuit capacity (kA²s)	24.0	57.3	78.9	105.8	150.4
Max. operation temperature ()	200	200	200	200	200
Max. fiber count	48	32	48	52	30
