OPGW Fiber Optical Cable
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | OPTELEC | |
| Model Number | OPGW |
Product Description
OPGW fiber optical cable
Product specifications:
1-Fiber core: 12~96fibers
2-Low attenuation coefficient and chromatic dispersion, insure cable's optics transmission charateristics
3- Proper design, precise fiber excess length control and distinct stranding process render the cable excellent mechanical and environmental characteristics
4- Anti-electromagnetism ability
5- Use high intensity aramid yarn as anti-pulling component, strong, light and small cable diameter, suitable for different climatic situation and installation span.
OPGW fiber optical cable applications:
Environment with high electric field strength in the power transmission system and area where frequent thunder happens.
OPGW standard compliance
IEEE P1222, ITU-T G.652, ITU-T G.655, IEC60794-1, DL/T 788-2001, YD/T 980-2002
OPGW cable technical parameter:
According fiber cores, weather condition, installation span, line voltage and etc.
OPGW Mechical characteristics:
Cable diameter: 12.6mm
Weight (kg/km): 134kg/km
Rated tensile strength: 18KN
Max. allowable stress: 7.5KN
Everyday stress (EDS):4.6KN
Ultimate operation stress:11KN
Min. bending radius: static:15D
dynamic: 20D
1.Excellent quality
2.Favoured price
3.Professional after-sales service&local training guide on site
4.Experienced workers team
5.ADSS/OPGW cable,hardware,cable fittings leading manufacturer from China,ISO certificated
6.Customized
