Home > Products > XLPE insulated power cable > medium voltage N2XSEYBY underground cable
medium voltage N2XSEYBY underground cable
- Qingdao
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | Taifa | |
| Model Number | N2XSEYBY cable | Insulation Material | XLPE | |
| Type | Medium Voltage | Application | Underground | |
| Conductor Material | Copper | Jacket | PVC |
Product Description
.
constructure
conductor; stranded copper
screen; copper wire
insulation: XLPE
armour: steel stripe
outer sheath: PVC
operating characteristics:
Max permissible continuous operating temperature of conductor 90°c
Max short-circuit temperature of the conductor shall not exceed (Max 5 seconds duration): cross-section of conductor 300 mm2
The anbient temperature under installations should not be below 0°c
The bending radius of single core cable should not be less than 20 times of the cable diameter ,the bending radius of multi-core cable should not be less than 15 times of the cable diameter
Package & Delivery
wooden drums or according to your requirements
delivery within 15 working days
