Intelligent Digital Multi-parameter Well Logging System
- Chongqing China
- T/T
You May Like
-
1000m Water Well Logging Winch Automatic Wireline Logger Winch
-
300m 500m 100m 1000m Well Logging Winch
-
2000m Geological Borehole Logging JGS-1B Water Well Logger
-
Geological Borehole Logging JGS-1B Water Well Logging System Well Logger
-
500M Well Logging Equipment Water Logging Equipment
-
Geophysical Borehole Logging Equipment With Gamma, Resistivity, SP,SPR
Product Details
| Place of Origin | Chongqing, China | Brand Name | Gold | |
| Model Number | JGS-1B |
Product Description
Intelligent Digital Multi-parameter Well Logging System
Using different parameters, JGS-1B can processing:
Coal field digital integrated logging.
Hydro-logical engineering digital integrated logging.
Solid metal ore digital integrated logging.
Other minerals digital integrated logging, etc.
External laptop (Desktop PC)
For upward logging, also for downward logging
Receive digital signal, analog signal
8 taps of power supply current, optional
Automatic sampling as per depth interval, sampling interval arbitrarily
Indoor simulation logging, repeatability observation of instruments and probes
Technical Specification:
12bit A/D conversion, program-controlled magnification K=0.5~128
Counting channel: f≤500KHz
Digital signal transmission frequency: 9600bit/s
Power supply cycle: 400ms
Current: 2mA~50mA optional
Signal input range: ≤±10V
Continuous working time: ≤24h
Power consumption: <200W
Volume: 420*260*210mm
Weight: <7kg
Working temperature range: -10℃~50℃
Working power supply: AC220V±10% 50HZ±5%
Logging speed: 0-30m/min adjustable (as per sampling interval)
System component:
Main instrument and software
Winch and cable
Well logging probes
