Deep Well Electric Log Instrument
- Chongqing
- T/T
You May Like
-
Well Winch for Lift and Lower Down Probe
-
Well Logging Tool, Logging Equipment and Well Logging Equipment for Geological Detection
-
JGS-1B 3000m Well Logging Survey System
-
Metal Mining Well Logging JCX Magnetometer
-
1000m Hydraulic Logging Winch
-
Made in China Intelligent Integrated Digital Well Logging Equipment
Product Details
| Place of Origin | Chongqing, China | Brand Name | Gold | |
| Model Number | Deep Well Electric Log Instrument |
Product Description
Deep Well Electric Log Instrument
1.Coal Field Digital Integrated Logging
2.Hydrological Engineering Digital Integrated Logging
3.Solid Metal Ore Digital Integrated Logging
4.Other Minerals Digital Integrated Logging
5.External Laptop (Desktop PC)
6.For upward logging, also for downward logging
7.Receive digital signal, analog signal
8.8 taps of power supply current, Optional
9.Automatic sampling as per depth interval, sampling interval arbitrarily
10.Indoor simulation logging, repeatability observation of instruments and probes
11.Membrane panel, attractive and durable.
Technical Specifications
1.12bit A/D Conversion, Program-Controlled Magnification K=0.5~128
2.Counting Channel: f≤500KHz
3.Digital Signal Transmission Frequency: 9600bit/s
4.Power Supply Cycle: 400ms
5.Current: 2mA~500 mA Optional
6.Signal Input Range: ≤±10V
7.Continuous Working Time: ≤24 hr
8.Power Consumption: <200W
9.Volume: 420×260×210mm
10.Weight: <7Kg
11.Working Temperature Range: -10°C~ +50°C
12.Working Power Supply: AC220V±10% 50Hz ±5%
13.Logging Speed: 0~30 m/min Adjustable (as per sampling interval).
