Tornos Metal CNC550A Cnc Lathe Slant /multi-purpose Lathe Machine

FOB Price

US$ 10,000 - 50,000 / Set

1 Set(Min. Order)

Port qingdao port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Turning Center
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	550mm	Place of Origin	Shandong, China
Brand Name	HaiShu	Model Number	CNC550A
Voltage	380v 50hz	Power(W)	15KW
Dimension(LWH)	375018002000mm	Weight	7500KG
Certification	ISO CE TUV	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

tornos metal CNC550A cnc lathe slant / multi-purpose lathe machine

Main technical parameters:

No.	Item	Unit	Technical parameters
No.	Item	Unit	CNC550A
1	Maximum turning diameter on lathe’ body	mm	550
2	Maximum workpiece length	mm	750/1000/1500
3	Maximum turning diameter	mm	500
4	Spindle nose type and code		A8
5	Hydraulic chuck	mm	300/200mm
6	Front spindle bore taper		1:20
7	Spindle bore	mm	75
8	Maximum load-bearing chucked components	kg	60
9	2 - servo spindle motor speed	mm/min	0-4000
10	Rapid traverse X / Z	mm/min	40000
11	CS1; CS2 main servo motor power	kW	15
12	X servo motor maximum torque	N.m	15
13	Z, Y servo motor maximum torque	N.m	15
14	Power Specifications	v	380±10%. 50Hz±1Hz
15	Carrier transfer time (one station)	s	1.6(Horizontal 12)
16	Carrier transfer repeat positioning accuracy		0.005"
17	X-axis travel	mm	350
18	Z-axis travel	mm	1100/13501850
19	B-axis(sub-spindle) travel	mm	1400/1650/2150
21	Biaxial dynamic docking concentricity	mm	0.005
22	Hydraulic servo turret form		Horizontal 12-station power turret
23	Knife handle size	mm	25*25
24	Net weight	kg	7500kg
25	Size(L×W×H)	mm	375018002000

Standard configuration:
1.Taiwan control system
2.Hydraulic solid chuck
3.Cutting cooling system
4.X.Z axis linear guide

5.The spindle unit and motor
6.Horizontal 12 station servo turret
7.BearingNSK

8.Fully enclosed protection system

If you are interested in tornos metal CNC550A cnc lathe slant / multi-purpose lathe machine, welcome to leave a message or send the inquiry to understand the details of machine.
