low price three-jaw chuck CKG1343B/CKG1350B pipe thread lathe

FOB Price

USD $35,000 - $38,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	630	Place of Origin	Shandong, China
Brand Name	Haishu	Model Number	CKG1343B
Voltage	380	Power(W)	11KW
Dimension(LWH)	360017501900	Weight	5500Kg
Certification	CE , ISO	After-sales Service Provided	Overseas third-party support available

Item	Unit	Specification
Model		CKG1343B	CKG1350B
Processing pipe thread diameter range	mm	φ270-435	φ270-500
Maximum workpiece swing diameter over bed	mm	1000
Maximum workpiece swing diameter skateboard	mm	610
Maximum distance between centers	mm	1500
Bed rail width	mm	755
Maximum distance across the dual chuck	mm	1940
Spindle bore diameter	mm	φ445	φ510
Spindle speed mode	mm	Tow steps,Frequency stepless
Spindle speed range	rpm	Low-grade: 23-120, High-grade: 65-340
Main motor power	KW	22
Clamping motor power	KW	3
X/Z axis rapid traverse rate	m/min	4/6
X/Z axis servo motor torque	Nm	15/22
X/Z axis repeat positioning accuracy	mm	0.012/0.016
X-axis maximum stroke	mm	450
Tailstock quill diameter	mm	φ140
Tailstock sleeve taper		MT6
Tailstock sleeve maximum stroke	mm	300
Cooling pump power	KW	0.125
Automatic lubrication interval time	min	12
) Dimensions (L × W × H)	mm	5000×2100×1650
Weight	kg	13000
