GT- 90-3-2 Led Street Light Lens
- Shanghai
- Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | GT | |
| Model Number | GT-92NA for led street lens | Material | Glass | |
| Usage | Optical | Structure | Other, convex-concave | |
| Shape | Aspheric |
Product Description
Specifications
1 This product is suitable for led lens that need to gather light.2 Our products are of high transmittance.
. Concave-convex
2. Diameter 90
3. Angle: 140*80 degree
4. Material: Optical glass
5. suitable for 20w-150w LED
Integrated High-Power Street Light Glass Lens(GT-90-3-2)
1. Specification:
1) Model: GT-90-3-2
3) Angle: 140*80 degree
4) Material: Optical glass (borosilicate),K9,BK7,B270
5) Light transmittance: 94%
6) working temperature : -50~500 °c
7) with silicon gasket and metal holder
2. Application:
This product is used for integrated chip 20-150w LED street light, tunnel light, outdoor light and so on.
product pictures
light distruction:
3. Advantages:
1) Made of borosilicate glass, high heat resistant: 500-600 centigrade
2) clear and transparent, no mould markd,no inside bubble and dirts
3) adopt high precision aspheric design and superior optical glass, strictly perform ROHS environmental standard
4) Customized lens available
4. GT lens company feature:
1) we can provide technical and professional optical system
2) we can supply the lens with advanced optical technology
3) we can offer lens group with different optical lens
4) we have studied out the reflector cup which will offer the well mixed facular and angle
5) we can provide optical modules and accessories.
5. Other products
Contact Us
- Wuxi Guangtai Glass Lens Co., Ltd.
- Contact nameLucy Song Chat Now
- Phone86-510-58452823
- AddressRM 505,NO.1 Building, Maoye Ho Park,Nanchang District, Wuxi, Jiangsu
