Home > Products > Barrier Terminal Block > PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch
Negotiable
/ Piece
1000 Pieces(Min. Order)
- Ningbo
- T/T Credit Card
You May Like
-
7.62mm Pitch 6P PCB Barrier Terminal Block KDT25 300V 15A with UL CE ROHS
-
Double Row Soldering Barrier Terminal Block Connector
-
Double Row Cream White Color Terminal Block 2KDS 300V 10A 7.62mm Pitch
-
Screw Brass Barrier Terminal Block with Cover 2KDS 300V 10A 7.62mm Pitch
-
Brass Dual Row Barrier Terminal Block Connector 2KDS 300V 10A 7.62mm
-
screw 12 pin terminal block connector
Product Details
| Place of Origin | Zhejiang, China | Brand Name | XIONGSHI | |
| Model Number | KDT55 | Type | Other, Barrier |
Product Description
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch
Product Description
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch Specifications
| KDT55 | |
| Approval | UL |
| Electrical | |
| Rated voltage | 300V |
| Rated current | 25A |
| Wire range | 22-12AWG |
| Withstand Voltage | AC2000V for 1 minute |
| Insulation Resistance | 500 mΩ / DC 500V |
| Materials | |
| Plastic Housing | PBT, UL94V-0, Black |
| Operation Temperature | -40℃- +105℃ |
| Terminal | Brass, Tin Plated |
| Screw | Steel, M4.0, Ni Plated |
| Torque Value | 10Kg/cm |
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch Drawing
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch, Right Angle Pin
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch Straight and Angle Pin
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch Straight Pin
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch Straight and Angle Pin
PCB Barrier Terminal Block KDT55 300V 25A 10mm Pitch Straight and Angle Pin
Certificate: CE, UL, ISO9001-2008, SGS, CQC
