HSHM1350TZ-D paper laminating machine for sheet
- 15 Set / Sets per Month
- Qingdao
- T/T
You May Like
-
HSHM1350TZ-D paper roller pressing machine
-
HSHM1350TZ-F PVC&Paper sticking on board woodworking machine
-
HSHM1350TZ-F Paper sticking machine
-
HSHM1350TZ-H MDF board decorative material sticking machine
-
HSHM1350TZ-H Membrane sticking flat mdf board manufacturing machine
-
HSHM1350TZ-F Flat board grainy paper(PVC) sticking membrane machine
Product Details
| Place of Origin | Shandong, China | Brand Name | HongSenHaoMai | |
| Model Number | HSHM1350TZ-D |
Product Description
Specifications
1350TZ-D Paper laminating machine1laminate paper or PVC on plan board
2finish dust clean, glue coat&dry, laminate and press
HSHM1350TZ-D Paper laminating machine for sheet
APPLICATION:
The paper sticking series are used to laminate the volumed decorative paper, the volumed PVC or
the volumed protecting film on the surface of plan boards such as the MDF, the particleboard, the
plasterboard and so on without bubble or wrinkle and with high efficiency.
Paper sticking machine
The features:
1. It can finish the dust collection, the glue spraying, the paper sticking, the hot and cold press
successively with high efficiency.
2. The rolls rising is contrals by pneumatic lifting system
3. The glue coating system adopts the overrunning clutch.
4. Following the glue coating, there is a heating system which used to dry the glue. What is more
the conveying length after the glue coating part is 3000mm which is long enough to take the board
out if the glue coating result is not perfect
5, there are three heating pressing roller and double cold pressing roller which make good pressing
result without the wrinkle and bubble
6. The loading part is 2500mm and the unloading part is 3000mm
7. It can load the material automaticlly
8. certification ISO 9001
TECHNICAL PARAMETER
Item | HSHM1350TZ-D |
Specification | Φ190X1350 |
Size of panel | 1220X2440mm |
Thickness of panel | 3-100mm |
Working speed | 5-17m/min |
Max.width | 1300mm |
Driving power | 14.77kw |
Heating power | 22kw*3 |
Overall dimension | 9800X2100X1800mm |
