Home > Products > laminating Machine Series > HSHM1350TZ-D Papaer and PVC Sticking Machine for Plane Surface
HSHM1350TZ-D Papaer and PVC Sticking Machine for Plane Surface
- qingdao
- T/T Credit Card
You May Like
-
HSHM1350TZ-C MDF Membrane Roller Press Machine
-
HSHM1350TZ-D Flat Board Membrane Press Sticking Machine
-
HSHM1350TZ-H Flat Board Membrane Sticking Machine
-
Paper Laminating Machine/PVC Laminating Machine on MDF Panel Board
-
HSHM1350TZ-H MDF Board Roller Press Membrane Sticking Machine
-
HSHM1350TZ-A Gypsum Board PVC Film Production Line
Product Details
| Place of Origin | Shandong, China | Brand Name | HSHM | |
| Model Number | HSHM1350TZ-D |
Product Description
Specifications
HSHM1350TZ-D Pvc sticking machine1glue coat hot &cold pressure
2for plane surface with invert controller
3CONVEY BELT
4ISO
HSHM1350TZ-D Papaer and PVC sticking machine for plane surface
Features of HSHM1350TZ-D
1. It can finish the dust collection, the glue spraying & drying the paper sticking, the hot and cold press successively with high efficiency.
2. All the rollers rising is controls by air cylinder system which makes even pressure and can protect the roller when accident.
3. The glue coating system adopts the overrunning clutch and the direction of the two glue coater roller is reverse which the glue coating result better and better.
4. Following the glue coating, there is a heating system which used to dry the glue and better to use in winter What is more the conveying length after the glue coating part is 3000mm which is long enough to take the board out if the glue coating result is not perfect
5. there are three heating pressing rollers and double cold pressing roller which make good pressing result without the wrinkle and bubble
6. The loading part is 2500mm and the unloading part is 3000mm
7. It equips with automatic material loading system which can save work.
8The dust collection system adopts double brush units which makes better result than the fan
MODEL | HSHM1350TZ-D |
Roller Specification | Φ190X1900mm |
Shortest work length | 500mm |
Longest work length | 3000mm |
Working width | 1850mm |
Work thickness | 2-45mm/90mm |
Conveying speed | 1-25m/min |
Conveying Motor power | 2.2kw |
Brush motor power | 0.5kw |
Glue drying power | About 15kw |
Material faltten power | 1.2kw |
Heating pressure power | 2.4kw |
Heat- roller specification | Φ190X1900mm*2 |
Cold-roller specification | Φ190X1900mm*3 |
Convey-roller specification | Φ190X1900mm*6 |
Max material work-width | 1850mm |
Overall dimension | 12800X2700X2000mm |
Net weight | 2500kgs |
