LM-SC5810P SD-SDI/ASI Converter, HD SDI to HDMI/VGA/CVBS Converter With BNC Port 1080p
- Shenzhen
- Credit Card PayPal
You May Like
-
LINK-MI LM-SC5325 Convert HDMI/VGA/AV Signal to SDI/HD SDI/3G SDI Signal
-
LM-HSD1 1080p HD HDMI to SDI BNC Digital TV Analog Converter
-
LM-PSD01 Supports De-embedding Audio From SDI Signal Pro 3G/HD/SD SDI to DVI Output Video Converter
-
LM-PCS01 Professional AV to SD/HD/3G SDI Converter Convert CVBS Input Signal to 3G/HD/SD SDI Output Signal
-
LINK-MI LM-SAV1 HD SDI Composite CVBS Converter Auto Video Mode Detection
-
2015 LINK-MI LM-SC5810HA BNC to Hdmi/AV CVBS 1080P SDI Converter for Moniter Camera
Product Details
| Brand Name | LINK-MI | Model Number | LM-SC5810P | |
| Place of Origin | Guangdong, China |
Product Description
Specificaton
SD-SDI/ASI Converter
♦ Support all type SDI resolution
♦ Carry 1 channel SDI signal loop out
♦ Support for OSD menu operation interface
LM-SC5810P SD-SDI/ASI Converter, SDI to HDMI/VGA/CVBS Converter With BNC Port 1080p
Introduction: SD-SDI/ASI Converter
LM-SC5810P SD-SDI/ASI Converter converts single channel SDI signal to HDMI signal and VGA signal and AV(CVBS signal). It integrates SDI Cable equalizer and re-clocker to enhance video performance and stability. Simultaneously it also separates and converts the audio signal of SDI, then embed it to HDMI signal or VGA Signal or AV signal . Then output analog audio DACs. It supports multiple resolution up to 1920x1080/60HZ.
SD-SDI/ASI Converter is a very good performance of SDI signal converter, the biggest characteristic is: the device itself built-in powerful processors, and realize automatic analysis interface device type, automatic matching interface equipment, automatic frequency automatic matching and frame rate conversion, automatic interlaced/conversion line by line, automatic color space transformation.
Product Picture: SD-SDI/ASI Converter
Model No.: LM-SC5810P
Product Type: SD-SDI/ASI Converter
SD-SDI/ASI Converter
Features: SD-SDI/ASI Converter
♦ Support all type SDI resolution.
♦ SMPTE 425M (A level and B level), SMPTE424M, SMPTE292M, SMPTE259M-C .
♦ Carry 1 channel SDI signal loop out.
♦ Support for OSD menu operation interface.
♦ Automatically detect the HDMI EDID information adaptive HDMI best mode .
♦ Support all formats asymmetric conversion.
♦ The signal lost blue screen warning.
♦ VGA output format can be specified 720p/1080p.
♦ Automatically embed SDI audio signal to HDMI signal.
♦ User selectable output format (HDMI and VGA and AV).
♦ Intelligent adaptationof PAL / NTSC.
Specification: SD-SDI/ASI Converter
Model | LM-SC5810P |
Input Interface | 1*BNC SDI |
Input Signal Type | SD-SDI(270Mbps),HD-SDI(1.485Gbps), 3G-SDI(2.97Gbps) |
Support Input Format | 525i 59.94,625i 50 720p 23.98/24/25/29.97/30/50/59.94/60 1080i 50/59.94/60 1080p 23.98/24/25/29.97/30/50/59.94/60 |
SDI Signal Range | 0.8Vp-p |
SDI Impedance | 75 ohms |
SDI Coupling Type | AC Coupling |
SDI signal jitter(typical value) | SD-SDI≤0.1UI HD-SDI≤0.2UI 3G-SDI≤0.4 UI |
Max. Input Coax Length | Belden 1694A: SD-SDI 400m, HD-SDI 200m,3G-SDI 140m Note: the above transmission distance for different specifications of the cable, test results will be different |
SDI Loop Out Interface | 1*BNC SDI |
HDMI/DVI Output Interface | 1*HDMI |
AV ( CVBS )Output Format | 1*BNC |
VGA Output Format | 1*VGA |
Size ( mm ) | 154*119*36 |
Power Supply | 5~24VDC |
Panel Description: SD-SDI/ASI Converter
Dimension: SD-SDI/ASI Converter
Wiring Diagram: SD-SDI/ASI Converter
Packing Contents: SD-SDI/ASI Converter
♦ 1 piece SD-SDI/ASI Converter
♦ 1 piece AC Adapter
♦ 1 PCS User Manual
