UTP cat5 cat 5e lan cable network cable
- shenzhen
- Credit Card
You May Like
-
wholesale UTP cat 5 cat 5e lan cable networking cable
-
factory offer high quality UTP cat5 cat5e ethernet cable different colors available
-
factory offer UTP cat5 cat5e cat6 ethernet cable
-
factory offer UTP cat5 cat5e lan cable 10m 20m 30m
-
factory offer UTP cat5 cat 5e RJ45 cable lan cable
-
UTP cat 5 cat 5e cable RJ45 lan cable
Product Details
| Place of Origin | Guangdong, China | Brand Name | OEM | |
| Model Number | cat5e lan cable | |||
| Number of Conductors | 8 |
Product Description
Specifications
cat5e lan cabledifferent colors optional
length optional
factory offer
wholesale UTP Cat5 Cat5E lan cable network cable
Specification:
Conductor | Insulation | Core Number | Drain | Shielded | Jacket | ||||||||||
AWG | Specification (mm) | Material | Thickness (NOM.mm) | Material | Thickness (NOM.mm) | OD (NOM.mm) | |||||||||
26 | 1/0.404 | HD-PE | 0.20 | 4P | 1/0.404TC | AL/Mylar | PVC or LSNH | 0.60 | 5.0 | ||||||
7/0.16 | HD-PE | 0.20 | 4P | 7/0.16TC | AL/Mylar | PVC or LSNH | 0.60 | 5.5 | |||||||
24 | 1/0.511 | HD-PE | 0.20 | 4P | 1/0.511TC | AL/Mylar | PVC or LSNH | 0.60 | 5.8 | ||||||
7/0.203 | HD-PE | 0.20 | 4P | 7/0.203TC | AL/Mylar | PVC or LSNH | 0.60 | 6.0 | |||||||
Description:
1.Specification: 4P+Mylar+D+AL
2.Rated Temperature: 60°C or 75°C
3.Unshielded twisted pairs:
4.Conductor: 26AWG or 24AWG Stranding or Solid Bare copper
5.Insulation: HD-PE
6.Drain Wire: 26AWG or 24AWG Stranding or Solid Tinned copper
7.Outer Shielded: AL-Mylar 100%(min) coverage
8.Unrip rope: optional
9.Jacket: PVC or LSNH
10.Impedance:100±15%Ω at 1~100MHz
11.Reference standard: YD/T1019-2001,ISO/IEC11801,ANSI/TIA/EIA-568B,UL 444
12.Flame Retardancy Standard: Passed CM or CMR
Features:
1.Al-Foil Shield Reduces the Interference and Data Loss
2.Fast and Reliable Connection
3.Twisted Pairs with Bright Color for Easy Recognition
4.Ripcord and Footmark for Convenient Use
5.Smooth Jacket for Easy Pulling in Tight Space
6.Color in Light Grey, Dark Grey, Blue, White or as per Your Requirement
Applications:
1.Computer Network Cabling Project.
2.Broadband Network Communication.
3.Digital ISDN Network and ATM 155Mbps Network
4.Ethernet Network
5.Audio and Data Transmission
