Good Quality Refrigeration Equipment Refrigeration Condensert for Cold Room and Chillers

FOB Price

US$ 500 - 1,200 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1.low noise
2.repadly cooling
3.Energy efficiency

Technical Parameters:

Unit model		HS261CH2	HS263CH3	HS303CH3	HS373CH3	HS453CH3	HS235CH3	HS603DH3	HS753DH3	HS903DH3
Refrigerant		R22
Suitable temperature (℃)		0~15
Power Supply		220V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
Scroll compressor models		C-SB261H5A-3.5hp	C-SB263H8A-3.5hp	C-SB303H8A-4hp	C-SB373H8A-5-hp	C-SB453H8A-6hp	C-SBR235H38A-7hp	C-SC603H8H-8hp	C-SC753H8H-10hp	C-SC903H8H-12hp
The largest operating current (A)		12.9	4.9	5.5	6.6	7.7	8.8	10.6	12.8	15.1
Condenser	Fan number	1	1	1	2	2	2	1	1	1
	Air flow (m³/h)	3600	3600	3600	5400	7200	7200	8800	12000	12000
	Power of fan	195	190	190	150*2	190*2	190*2	700	780	780
Connecter	Inhale interface (mm)	Φ16	Φ16	Φ16	Φ19	Φ19	Φ19	Φ22	Φ22	Φ22
For liquid interface (mm)		Φ12.7	Φ12.7	Φ12.7	Φ12.7	Φ12.7	Φ16	Φ16	Φ16
The weight of unit(kg)		87	87	90	107	112	114	177	180	186
Size	Length(mm)	1020	1020	1020	1030	1030	1030	1000	1000	1000
	Width(mm)	490	490	490	490	490	490	1000	1000	1000
	Height(mm)	835	835	835	1290	1290	1290	1470	1470	1470
Condensation temperature		45℃
