CE Certification Compresoor Type Compressor Condensing Units Parts
US$ 100 - 2,000
/ Set
1 Set(Min. Order)
- lianyungang/shanghai
- Credit Card
You May Like
-
CE Certification and Compressor Type Condensing Unit
-
Factory Price Compressor Condensing Units Parts Used for Refrigeration Equipment
-
Factory Price Refrigeration Equipment Single Temperature Compressor Condensing Units
-
Condensing Unit Type Refrigeration Compressor for Cold Room
-
Sanyo/Copeland Brand Remote Compressor Unit China Manufacturer
-
Cold Room Spare Parts Refrigeration Compressor Unit
Product Details
| Place of Origin | Jiangsu, China | Brand Name | sanye condenser units parts | |
| Model Number | HS261CH2 | Type | Other, chiller, Chiller | |
| Application | Refrigeration Parts | Certification | CE |
Product Description
condensing units
Technical Parameters:
Technical Parameters:
| Unit model |
| HS261CH2 | HS263CH3 | HS303CH3 | HS373CH3 | HS453CH3 | HS235CH3 | HS603DH3 | HS753DH3 | HS903DH3 |
| Refrigerant | R22 | |||||||||
| Suitable temperature (℃) | 0~15 | |||||||||
| Power Supply | 220V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | |
| Scroll compressor models | C-SB261H5A-3.5hp | C-SB263H8A-3.5hp | C-SB303H8A-4hp | C-SB373H8A-5-hp | C-SB453H8A-6hp | C-SBR235H38A-7hp | C-SC603H8H-8hp | C-SC753H8H-10hp | C-SC903H8H-12hp | |
| The largest operating current (A) | 12.9 | 4.9 | 5.5 | 6.6 | 7.7 | 8.8 | 10.6 | 12.8 | 15.1 | |
| Condenser | Fan number | 1 | 1 | 1 | 2 | 2 | 2 | 1 | 1 | 1 |
| Air flow (m³/h) | 3600 | 3600 | 3600 | 5400 | 7200 | 7200 | 8800 | 12000 | 12000 | |
| Power of fan | 195 | 190 | 190 | 150*2 | 190*2 | 190*2 | 700 | 780 | 780 | |
Connecter | Inhale interface (mm) | Φ16 | Φ16 | Φ16 | Φ19 | Φ19 | Φ19 | Φ22 | Φ22 | Φ22 |
| For liquid interface (mm) | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ16 | Φ16 | Φ16 | ||
| The weight of unit(kg) | 87 | 87 | 90 | 107 | 112 | 114 | 177 | 180 | 186 | |
| Size | Length(mm) | 1020 | 1020 | 1020 | 1030 | 1030 | 1030 | 1000 | 1000 | 1000 |
| Width(mm) | 490 | 490 | 490 | 490 | 490 | 490 | 1000 | 1000 | 1000 | |
| Height(mm) | 835 | 835 | 835 | 1290 | 1290 | 1290 | 1470 | 1470 | 1470 | |
| Condensation temperature | 45℃ |
