Sanye Manufacture 3.5-12hp Compressor Condensing Unit for Cold Room Storage With AC Fan
US$ 500 - 1,200
/ Set
1 Set(Min. Order)
- Lianyungang
- T/T Credit Card
You May Like
-
Sanye Manufacture 3.5-12hp Ccondensing Unit Prices for Cold Room Storage With AC Fan
-
China 2-10hp R22 Condensing Unit for Cold Room Storage With AC Fan
-
China Cooler Unit of Room for Cold Room Storage With AC Fan
-
Sanye Manufacture 3.5-12hp Condensing Unit Prices Refrigerator Parts for Cold Room Storage With AC Fan
-
CE Certification and Parallel Compressor Condensing Unit Type Compressor Condensing Unit
-
CE Certification Compresoor Type Compressor Condensing Units Parts
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Sanye | |
| Model Number | HS261CH2 | Type | Other, Chiller | |
| Application | Refrigeration Parts | Certification | CE |
Product Description
Specifications
refrigeration condensing unit for cold room storage1.low noise
2.repadly cooling
3.Energy efficiency
4Use the fan gover
Technical Parameters:
| Unit model |
| HS261CH2 | HS263CH3 | HS303CH3 | HS373CH3 | HS453CH3 | HS235CH3 | HS603DH3 | HS753DH3 | HS903DH3 |
| Refrigerant | R22 | |||||||||
| Suitable temperature (℃) | 0~15 | |||||||||
| Power Supply | 220V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | |
| Scroll compressor models | C-SB261H5A-3.5hp | C-SB263H8A-3.5hp | C-SB303H8A-4hp | C-SB373H8A-5-hp | C-SB453H8A-6hp | C-SBR235H38A-7hp | C-SC603H8H-8hp | C-SC753H8H-10hp | C-SC903H8H-12hp | |
| The largest operating current (A) | 12.9 | 4.9 | 5.5 | 6.6 | 7.7 | 8.8 | 10.6 | 12.8 | 15.1 | |
| Condenser | Fan number | 1 | 1 | 1 | 2 | 2 | 2 | 1 | 1 | 1 |
| Air flow (m³/h) | 3600 | 3600 | 3600 | 5400 | 7200 | 7200 | 8800 | 12000 | 12000 | |
| Power of fan | 195 | 190 | 190 | 150*2 | 190*2 | 190*2 | 700 | 780 | 780 | |
Connecter | Inhale interface (mm) | Φ16 | Φ16 | Φ16 | Φ19 | Φ19 | Φ19 | Φ22 | Φ22 | Φ22 |
| For liquid interface (mm) | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ12.7 | Φ16 | Φ16 | Φ16 | ||
| The weight of unit(kg) | 87 | 87 | 90 | 107 | 112 | 114 | 177 | 180 | 186 | |
| Size | Length(mm) | 1020 | 1020 | 1020 | 1030 | 1030 | 1030 | 1000 | 1000 | 1000 |
| Width(mm) | 490 | 490 | 490 | 490 | 490 | 490 | 1000 | 1000 | 1000 | |
| Height(mm) | 835 | 835 | 835 | 1290 | 1290 | 1290 | 1470 | 1470 | 1470 | |
| Condensation temperature | 45℃ |
Why choose us?
1.We are a professional refrigeration manufacturer in china.
2.We are not just partner but also friends
3.we supply the best service and good quality products
4.we have a professional design team and advance technology and world class assembly line
Main components:
compressor : Danfoss scroll compressor , Copeland compressor,lanhai rotary compressor
- 1mm galvanized case,
- fan speed control
- Danfoss spare parts:dual pressure switch,sight glass,drier filter,
- ABB electrical:isolator switch,contactor,time relay,MCB,overload,fault indicator light,
- Liquid receiver with fusible plug from 2-4HP,from 5-6HP with Castel safety release valve,
- Condenser with axial fan motor
- Service valve,
- 3 phase monitoring device
- Low side / high side gauge
- Compressor jacket,
- Suction filter,
- Acoustic lining
Fan speed control
ABB isolator switch,contactor,overload protector,time delay
