Antenna Manufacturer 5725-5850MHz(5.8GHz) 12dBi Outdoor Omni Fiberglass WiFi Long Antenna
- Shenzhen or HongKong
- T/T Credit Card PayPal
You May Like
-
Ameison 806-960/1710-2500 MHz 3 dBi Indoor Ceiling Mount DAS GSM WiFi Omni Antenna
-
Antenna Manufacturer 698-960/1710-2700MHz 3dBi DAS indoor Ceiling Antenna
-
DCS 1710 - 1880 MHz 11 dBi wifi 30km Omni wireless Fiberglass Antenna
-
1.2G 1100 - 1300 MHz 11dBi Omni amplifier Fiberglass Antenna
-
GSM 824 - 960 MHz 12 dBi Omni directional outdoor wifi amplifier Fiberglass Antenna
-
GSM 824 - 960 MHz 10 dBi Omni directional WIFI amplifier Fiberglass Antenn
Product Details
Place of Origin | Guangdong, China | Brand Name | AMEISON | |
Model Number | AMXF-5800-12 |
bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
Product Description
Antenna Manufacturer 5725-5850MHz(5.8GHz) 12dBi Outdoor Omni Fiberglass WiFi Long Antenna
It is a Profession Grade Omni-Directional Down-Tilt antenna that can be used for Commercial installations. The antenna features high gain and superior VSWR.
The unit is optimized for the 5.8GHz band applications.
The pattern is electrically tilted downward to improve coverage from higher mounting elevations in difficult sites such as apartment complexes and similar installations.
It is is a very compact yet high performance omnidirectional WiFi antenna designed for the 5.8GHz ISM and UNII band, ideally suited for close-in systems, typically found in apartment complex installations, neighborhood networks, industrial complexes, mobile home parks, marinas, truck stops and shopping centers.
Features:
Durable UV-stable fiberglass radome for all weather operation
Sealed end cap and drain hole at the base for all weather operation
Integral N-Female connector
Antenna mounts included
Can be installed indoors as well as outdoors
Applications:
5.8GHz UNII applications
5.8GHz ISM applications
5.8GHz Wireless LAN systems
Public Wireless Hotspot/WiFi Access Points
Wireless Video Systems
AMXF-5800-12 Electrical Specifications | |
Frequency range(MHz) | 5725~5850 |
Bandwidth(MHz) | 125 |
Gain(dBi) | 12 |
Half-power beam width(°) | H:360 V:6 |
VSWR | ≤1.5 |
Input Impedance(Ω) | 50 |
Polarization | Vertical |
Maximum input power(W) | 100 |
Lightning protection | DC Ground |
Input connector type | N Female or Requested |
Mechanical Specifications | |
Dimensions (mm) | Φ20*580 |
Antenna weight(kg) | 0.34 |
Operating temperature(°c) | -40~60 |
Rated Wind Velocity(m/s) | 60 |
Radome color | Gray |
Mounting way | Pole-holding |
Mounting hardware(mm) | 35 - 50 |
