AMEISON 806-960/1710-2690/1710-2690MHz 4dBi Dual Band Dual Polarized DAS MIMO Omni indoor dc ceiling antenna
- Shenzhen or HongKong
- T/T Credit Card PayPal
You May Like
-
Antenna Manufacturer 5dBi UHF Fiberglass Omni Antenna 433MHz
-
Antenna Manufacturer 824-960/1710-2700MHz 2/3dBi White DAS/AWS/ GSM/CDMA/PCS/3G/WLAN/4G/LTE Omni Patch Antenna
-
Antenna Manufacturer 450MHz 5dBi UHF VHF Radio Omni Fiberglass Antenna
-
Antenna Manufacturer 2400-2483MHz 12dBi Wifi Fiberglass 2.4 ghz omni directional antenna
-
Antenna Manufacturer 1710-1880MHz 8dBi Fiberglass DCS AWS Outdoor Omni Antenna
-
Antenna Manufacturer 2400-2483MHz(2.4GHz) 15dBi Wifi Fiberglass Outdoor Omni Antenna
Product Details
Place of Origin | Guangdong, China | Brand Name | AMEISON | |
Model Number | AMXC-8027V2H1-4 |
bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
Product Description
AMEISON 806-960/1710-2690/1710-2690MHz 4dBi Dual Band Dual Polarized DAS MIMO Omni indoor dc ceiling antenna
806-2690MHz Omni directional Ceiling Mount Antenna
AMXC-8027V2H1-4
Feature:
Exquisite appearance
Suitable for ceiling mounting
Optimized dimension
Vertical and Horizontal
Application:
Indoor omni directional coverage
GSM/CDMA/PCS/3G/WLAN/4G LTE system
AMXC-8027V2H1-4 Electrical Specifications | ||
Interface | Vertical | Horizontal |
Frequency range(MHz) | 806~960/1710~2690 | 1710~2690 |
Gain(dBi) | 2 / 3 | 4 |
Half-power beam width(°) | H:360 V:90/60 | H:360 V:55 |
V.S.W.R. | ≤1.5 | ≤1.5 |
Third-order Intercept Point(dBm) | ≤-107 | |
Isolation between ports (dB) | ≥25 | |
Cross-polar ratio(dB) | ≥15@0º ≥10@+/-60º | |
Input Impedance(Ω) | 50 | |
Polarization | Vertical and Horizontal | |
Maximum input power(W) | 50 | |
Lightning protection | DC Ground | |
Input connector type | 2xN Female | |
Mechanical Specifications | ||
Dimensions(mm) | Φ185*82 | |
Antenna weight(kg) | 0.35 | |
Operating temperature(°c) | -40~60 | |
Radome material | ABS | |
Radome color | white | |
Mounting way | Screw down nut |
Dual Polarized Design (Vertical and Horizontal polarization)
This antenna features an unique array of cross dipole elements.
The antenna is fed via two N-Female ports, one for vertically polarized and one for horizontally polarized signals.
These feature makes these antennas ideal for polarization diversity systems.
This is a high performance ceiling mount antenna specifically designed for DAS (Distributed Antenna Systems) which are used to distribute Cellular and WiFi signals throughout a building or area.
The Multi-Band design of this antenna eliminates the need to purchase different antennas for each frequency.
This simplifies installations since the same antenna can be used for a wide array of in-building wireless applications where wide coverage is desired.
The aesthetically pleasing design of this antenna makes it ideal for use in almost any indoor environment.
It can be easily mounted through a single 11/16" hole in a solid or suspended ceiling up to 1" thick.
This antenna features a 12 inch coax lead terminated with an N-Female connector.
Special order connectors are also available.
