Product Details
| Condition | New | Type | Drying Oven | |
| Place of Origin | Guangdong, China | Brand Name | LIANHE | |
| Model Number | LH-DH | Voltage | 220/380V 50/60Hz | |
| Power(W) | 15KW | Dimension(L*W*H) | 2.6*1.4*2.3M | |
| Weight | 800KG | Certification | CE,ISO,CCC,UL | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Hot Air Circulation drying Oven, tray dryer, drying machine
1.high quality
petivite price
3.good aftersale servide
Descriptions:
LH-MH
series hot air circulation oven adopts noise elimination and thermal stable axial flow fan and automatic temperature control system. The entire circulation system is enclosed to make that the heat efficiency of the drying oven increases from 3~7% of the traditional drying oven to 35~45% of the present one. The highest heat efficiency can be up to 50%. The successful design of CT-C hot air circulation oven makes that the hot air circulation drying oven in our country reach the advanced level in the world. It saves energy and increases the economic benefit. In1990,the medical management bureau of the State issued the industry standard and the uniform type is RXH.
This drying oven is suitable for the material and product hot solidification and dry de-watering in the pharmaceutical, chemical, food, farming, side-product, aquatic product, light industries, heavy industries and others industries. Such as: raw material medicine, crude drug, prepared herbal medicine of Chinese traditional medicine, plaster, powder, particle, drinking agent, pill, packing bottle, pigment, dyestuff, de-watering vegetable, dried fruit piece, sausage, plastics, resin, electric component, baking varnish and etc.
Most hot air is circulated in the oven. The Heat efficiency is high and the energy is saved. By using the forced ventilation function, there are adjustable air distribution plates inside the oven. The materials can be dried uniformly. The heating source might be steam, hot water, electricity and far infrared. With a wide selection. The whole machine is low in the noise. The operation is in balance. The temperature is controlled automatically. The installation and maintenance are easy. The application is wide. The machine can be used for drying various materials and is versatile drying equipment.
Explanation
1. Options of heat source: steam, electricity, or far infrared, or both steam electricity.
2. Drying temperature: steam heating 50-130 °C, Max.140 °C.
3. Electricity and far infrared:50-300 °C .Automatic control system and computer control system on request.
4. Commonly used steam pressure 0.2-0.8Mpa (2-8 bar).
5. For CT-C-I, electric heated, rated power consumption: 15Kw, real consumption: 5-8Kw.
6. The special requirements should be indicated at the time of order.
7. Please consult as for any special requirements.
8. For operation temperature of over 140 °C or less than 60 °C, please indicate when order.
9. The ovens and baking trays made by our factory are uniform in dimensions, and can be exchanged each other.
10. Baking plate dimensions: 460*640*45mm
Technical paramters
Model | Drying capacity(kg/lot) | Electric heating power(kw) | Fan power(kw) | Overall dimensions W*D*H(mm) | Equipped drying shelf(set) | Drying plate equipped (pc) | Temperature automatic control box | Total weight(kg) |
CT-C-O | 60 | 6-9 | 0.45 | 1380*1200*2000 | 1 | 24 | available | 820 |
CT-C-I | 120 | 15 | 0.45 | 2260*1200*2000 | 2 | 48 | available | 1580 |
CT-C-II | 240 | 30 | 0.45*2 | 2260*2200*2000 | 4 | 96 | available | 1800 |
CT-C-III | 360 | 45 | 0.45*3 | 2260*3200*2000 | 6 | 144 | available | 2100 |
CT-C-IV | 480 | 60 | 0.45*4 | 4480*2200*2270 | 8 | 192 | available | 2800 |
exported to USA,CANADA,EUROPE AFRICA AND SO ON
After-sales Service:
1. The machines' quality that we sold will be guaranteed for 1 year.
2. Provide you life-long maintenance.
3. Within 24 hours we will send service technicians to the your site.
4. Under normal circumstances, the company will be equipped with conventional spare replacement parts to meet your requirements at any time
certificate
You can find Coco any time
Coco Ruan
Whatsapp/ph:8613189034894
skype:lianhe1wu
Lianhe established in 1992.(P1)
Lianhe has more than 115 workers.
Lianhe can provide 6 whole lines for daily cosmetic and perfume.(P2)
Lianhe has 5 engineers for R&D.(P3)
Lianhe has 4 persons for QC.All our machines should be tested before delivery,the testing video also have to send to customers for sure.(P3)
Lianhe has more than 7 exhibitions for our machines.(P4)
Lianhe can provide you wholeline service.(P5)
P1
P2
P4 P5
Any comments are appreacited
1.A.Are you factory?How many workers do you have?
B.Yes,we are factory. One is in guangzhou and the other one is in my boss's hometown.Almost 100 person working for this 15 years old factory.
2.A.What about after sale service?
B.We provide two year warrantly for big machines like hydraulic homogenizer vacuum emulsifying mahcines and mixers series.One year for small filling machines like semi-automatic labeling machines series.
However,we provide wearing parts(not caused by improper operating) for free in the warrantly(except delivery fee)
3.A.What about install?
B.Our engineers will be sent according to your project.However,the customer will pay the economic air tickets round trip and arrange the accommodation for them.
4.A.What can you do if the machines meet problem?
B. The picture or video to show the problem should be provided,then we will send you teching video based on the small machines,if for the big problem for big machines ,engineers will be sent.Please check question 3 to make sure the fees.
5.A.How can you control the quality and delivery?
B.All our machines should be tested before packaging,wooden packaing is strong and safety for long delivery .
Welcome to your advice for our machines and our service,your happy my happiness.
Please no hasitate to contact with me.Or leave me message.Thank you
