JS-500 mortar mixer

FOB Price

USD $100 - $100,000 / Set

1 Set(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Port QING DAO
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	He Nan Zhong Chong Machinery	Model Number	JS500
Motor Power	24.75KW	Mixing Power	18.5KW
Charging Capacity	500L	Reclaiming capacity	800L
Speed of Mixing Drum	35	Water Supply Mode	automatic
Discharge Way	automatic	Outline Dimension	446130505225

Product Description

Specifications

1 high efficiency
2 electrical integration
3 fast , clearly discharging
3 low energy consumption, noise.

JS series of concrete mixer twin-shaft compulsory mixer

Product description:

This series of equipments have double superiority. It can be operated independently and also can use with ingredients machine for a simple concrete mixing plant. It still can provide supporting host for mixing station. It can apply to all kinds of large, medium and small prefabricated-component factory and roads, bridges, water conservancy, wharf industrial and civil construction engineering. It can mix dry, plasticity, mobility, light-weight aggregate, other concrete and all kinds of mortars. It is a new and efficient model and is applied widely.

It supports leg length which designed as followings: JS500 is 1500mm,JS750 is 1600mm,JS1000 is 3500mm and 4000mm,JS1500and JS2000 is 4500mm.Users can use with self-dump trucks, dump truck, mixer, also can re-create according to user's special requirements, to meet users’ different needs.

Features:

1. reasonable structure design

2. new layout

3. convenient usage and maintenance.

Main technical parameters:

Type		JS500	JS750	JS1000	JS1500	JS2000
Discharge capacity		500L	750L	1000L	1500L	2000L
Feeding capacity		800L	1200L	1600L	2400L	3200L
Productivity		≥25m³/h	≥37.5m³/h	≥50m³/h	≥75m³/h	≥100m³/h
The largest aggregate diameter (Pebble / gravel)		80/60mm	80/60mm	80/60mm	80/60mm	80/60mm
Mixing blades	Speed	35r/min	31r/min	25.5r/min	25.5r/min	23r/min
Mixing blades	Amount	2×7	2×7	2×8	2×10	2×10
Stirring motor	Type	Y180M-4	Y200L-4	T225S-4	Y225M-4	Y280S-4
Stirring motor	Power	18.5KW	30KW	37KW	45KW	75KW
Uptrend Motor	Type	YEZ132S-4-B5	YEZ132M-4-B5	YEZ160S-4	YEZ180L-4	YEZ180L-4
Uptrend Motor	Power	5.5KW	7.5KW	11KW	18.5KW	22KW
Pump Motor	Type	50DWB20-8A	65DWB35-5	KQW65-100L	KQW65-100L	CK65-20L
Pump Motor	Power	>750W	1.1KW	3KW	3KW	4KW
The upgrade speed of hopper		18m/min	18m/min	21.9m/min	23m/min>	26.8m/min
Outside Dimensions (L×W×H)	Transport status	3050×2300 ×2680mm	3650×2600 ×2890mm	4640×2250 ×2250mm	5080×2250 ×2440mm	5860×2250 ×2735mm
Outside Dimensions (L×W×H)	Working condition	4461×3050 ×5225mm	4951×3650 ×6225mm	8765×3436 ×9540mm	9645×3436 ×9700mm	10720×3870 ×10726mm
Weight		4000kg	5500kg	8700kg	11130kg	15000kg
Discharge height		1500mm	1600mm	2700 mm	3800mm	3800mm

Note: for information purposes only, any questions please contact us!
