new type sheet metal folding machine
- 20 Set / Sets per Month
- tianjin new port
- T/T
You May Like
Product Details
| Type | Tile Forming Machine | Tile Type | Colored Steel | |
| Use | Roof | Place of Origin | Hebei, China | |
| Brand Name | JCX |
Product Description
Specifications
sheet metal folding machine 1. Nice appearence.2. Low noise.
3. High efficiency.
4. Good quality.
5. Esay control.
roll forming machne Main technical parameters:
1. Rack: Using 300H steel welding
2. Forming Machine-driven feeding frame forms: lateral slide-style
3. Forming Machine Type: wall-type chain drive. Wall thickness of 16 mm.
4. Shaft Diameter: 75 mm
5. Chains: 1 inch single-row
6. Forming Motor Power: 4KW
7. Forming Machine speed: 1.0m/min
8. Forming Machine Road Number: 12
9. Roll Material: high quality 45 # steel Duan playing pieces
10. Hydraulic station motor: 4kw °
11. Rolling thickness :0.3-1 .0 MM
12. Materials Expand Width: 1200mm
13. The computer use of PLC, Taiwan and Taiwan reached
14. The machine weighs about 4 tons, length of 7 meters wide and 1.45 meters, 1.2 meters high.
.The forming rollers are the key of roll forming machine. We use CAD to design and manufacture the rollers. After CNC lathe, the forming rollers will be harden by vacuum heat treatment and finished the profiles again. These processes make the more accurate forming rollers, avoid the deformation during heat treatment and ensure the rollers preciseness and wear-resisting ability.
