ERW89 Pipe Mill
- Xingang China
- T/T
You May Like
Product Details
| Condition | New | Type | Pipe Production Line | |
| Pipe Material | Carbon Steel | Application | Drain Pipe | |
| Place of Origin | Hebei, China | Brand Name | ZTZG | |
| Model Number | ERW89 | Certification | CE | |
| Warranty | 1 YEAR | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Commodity: ERW pipe mill
I. Brief introduction:
89mm welded pipe production line is designed to produce welded pipes of 42mm-89mm in OD and 1.5mm-4.5mm in wall thickness, as well as corresponding square and rectangle tube.
II. Basic Technical Information:
Circular Pipe Size | 42mm - 89mm |
Pipe Thickness | 1.5mm-4.5 mm |
Square Pipe Size | 32mm*32mm-70mm*70mm |
Pipe Thickness | 1.5mm-3.5 mm |
Material | Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80 |
Pipe Length | 6-12m |
Length Tolerance | ±3mm |
Mill Speed | 20-70 m/min |
Direction | From left to right or decide by your side. |
Electricity Input Power | Belong to confidential information,detail parameters will be known in the quotation list. |
Workshop Area | |
Tube Bottom Passline |
III. The technical flow of the production line
Uncoiling→Shear & butt welding→Cage looping (Accumulating)→Forming →HFwelding→Removing & outsied Bead →Cooling→Sizing→Cutting off→Conveying →Downloading → Packing →Warehousing
IV. Makeup of tube mill line
1. Double-reel Mechanical Uncoiler
2. Shear & Butt Welder
3. Cage Loop(Accumulator)
4. Tube mill
5. Solid State H.F. welder
6. NC Flying Saw
7. Output Rollway
8. Rollers
