10kV digital megger with strong anti-interefence Intelligent Digital High Voltage

1. Q:What is voltage of  megger insulation resistance meter / tester?

      A:Voltage: 1KV / 5KV / 10KV

2. Q:What is the resistance test range of megger insulation resistance meter / tester ?

Description:

Insulation resistance tester dedicated to the measurement of watercooled generator test, but also can be used for laboratory or field testing insulation testing to do. Output current greater than 25mA. The maximum output voltage of 2500V. Includes highprecision microcurrent measurement system,digital boost system. Just use a highvoltage lines and a signal line connecting the test product can be measured. Automatic measurement, the results from the large screen liquid crystal display, and store the results.

Features:

1. 32-bit micro-controller, Chinese user interface, easy to operate.

2. Automatically calculates the absorption ratio and the polarization index, and automatically save 15 seconds, 1 minute, 2 minutes, 10 minutes to facilitate analysis of data per minute.

3. Output current,  short-circuit currents greater than 5mA.

4. A fully enclosed highvoltage generator module technology, the protection of the internal resistance, safe and reliable.Anti-interference ability, to meet the EHV substation on-site operation.

5. Automatic discharge test is completed, and real-time monitoring the discharge process.

Technical Data:

Accuracy: ± 10%

Range: 0.1M ~ 200GΩ

Test voltage: 0.5Kv ,1KV,2.5KV,5KV

Short circuit current:> 5mA

Measuring time: 1 minute to 10 minutes (with the measurement related)

Power Supply: 180 ~ 270VAC, 50Hz/60Hz ± 1% (utility or generator power)

Working Environment: Temperature -10 ~ 40 ℃,

relative humidity 20 to 80%.

From the date of purchase within one year instrument, is a product quality problem free repair replacement, lifetime supply of maintenance and technical services. The instrument has found anomalies or malfunctions please contact us to arrange the most convenient treatment options.

HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.

What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.

Our main products are Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on.
