1T-2T Construction Passenger Sc100 Construction Lifter

  SC 100/100   construction passenger elevator construction lift

  I. Main fetures of   sc100 construction lifter

Our construction elevator is specially used for the construction of high rise buildings,residence,towers,chemnys, towers and like so and.

Adopting advanced technology, it can also be equiped with electrical overload warming device, auto  landing-call equipment or autimatic leveling device according to your requirement.

1.High precise accessories and durable main parts

2.Good qualified raw materials and strict producting techniques

3.SGS;ISO9001:2000 certificate of quality

4.Adopt international standards approval certificate

a. Cage:single or double

b. Master section:Adopt Welding Robort to weld, reliable in quality and elegant in appearance.

c. Cabin(operating board):provide a comfortable environment for the driver

d. Attanchment frame:the connection device between frame rail and building to ensure the stability of frame rail and all the structure.

e. Safety device: floor-call device, autimatic leveling device, overloading warming device and so on.

 All the structure adopt Tooling fixed technology to ensure stable perfomance and stability.

III. Some pictures of   sc100 construction lifter

   construction passenger elevator construction lift

The standard section

 Mast is composed of numerous mast sections connected with high-strength bolts. Mast serves as either the track for upward and downward movement of cages or load bearing member, bearing dead weight of construction hoist and working load.

    Mast  section is welded with 4 column tubes, 3 angle steel frames and counterweight tracks ,and is installed with 2 racks(one rack for product with single cage),The length of each mast section is 1,508mm.Mast section has a rectangular profile, of which , the specification is 710mmx710mm.

Mast  is connected with building via the tie-in system to ensure the overall structural stability.

  Anti-dropping Safety Device
