low cost prefabricated eps houses,flexible building materials for labour office , temporary camp

FOB Price

US$ 50 - 85 / Unit

1 Unit(Min. Order)

Port XINGANG(TIANJIN)
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Beijing, China	Brand Name	CDPH
Model Number	K type	Material	Steel
Use	Carport, Hotel, House, Other, Office, Shop, Toilet, Warehouse, Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Warehouse

Product Description

House description:

1) Structure: light steel as its main frame, strong and reliable; sandwich panels as roof and wall boards, Heat insulation and beautiful decoration.

2) Environmental protection and economized: prefab houses are reasonable in design, can be removed or recycled more than 5 times, and it can service 10 years or longer.

3) Applications: prefab houses can be used as permanent & temporary residence, laborers accommodation, office, workshop, warehouse, etc.

4) Advantages: Flexible layout

Quick installation

1storey, 2 storey, 3storey

Can be with elevated floor

5) Inside facilities: Except the house body, we still can provide Floorings, ceiling, water system; electric system, sanitary, etc. for clients' choice.

6) Quick installation: It is convenient to install, Eight skilled workers can finish 100m2 in 8 hours.

7) Transportation: The completely knock-down of prefab house components can save more space of the sea container and make the freight cost of house much lower

The detail technica information is as follows:

No.	Sort	Name	Specification
1	Specification	length	NM+160(N=4,5,6... M is modular, 1M=1820mm)
2		Width	NM+160(N=3,4,5... M is modular, 1M=1820mm)
3		Wall height	5715mm	8565mm
4		Clear height	Ground floor :2425mm First floor :2685mm	Ground floor :2425mm First floor :2425mm Three floor:2685mm
6	Standard accessory	Wall board	50mm EPS sandwich panel, 0.3mm color steel sheet and 12kg/m3 polystyrene foam density inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.663w/.k.
7		Roof board	50mm EPS sandwich panel, 0.3mm color steel sheet and 12kg/m3 polystyrene foam density inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.663w/.k.
8		Door	SIP with steel frame, single door with dimensions of 955*2024mm, furnished with a cylinder lock with 3keys. Doorframe is made of 1.5mm steel, 50mm thick EPS insulation foam.
9		Window	PVC , white color, with dimensions of 1750*950mm, glazed with glass in a thickness of 5mm, two bay sliding, supplied with fly screen.
10		Base beam	C style steel. material:Q235.Painted
11		Column	Double C style steel. material:Q235. modular pace: 1830mm. Painted
12		Floor beam	Parallel truss(C style steel). material:Q235 Painted
13		Floor purline	Gable truss(C style steel). material:Q235. Painted
14		Roof beam	Gable truss(C style steel). material:Q235.Painted
15		Roof purline	Gable truss(C style steel). material:Q235.Painted
16		Inclined brace	round steel, material:Q235. Galvanized and Painted
17		Stair	Steel stair, material: Q235. material:Q235.Painted
18		Tread	press steel board
19		Floor stab	14mm plywood
20	Option	Elevated ceiling	Ceiling of mineral wool acoustic panel, or Ceiling of aluminium panel
22		Decorative floor	PVC, laminated or ceramic tile
23		Drainage system	Provided plan, design and construction
24		Electric system	Provided plan, design and construction
25	Technical parameter	Bearing load	50kg/m²
26		Wind pressure:	0.6KN/M2	0.45KN/M2
27		Fire proof	B2 grade
28		Resistant temperature	-20 to 50
29		The resistant earthquake grade	7 fission activate.

Production Capacity:

Product Line Name	Production Line Capacity	Actual Units Produced(Previous Year)
Modular House	100,000 m2 / Month	620,000 m2

Export Market Distribution:

Market	Revenue(Previous Year)	Total Revenue (%)
South America	confidential	8.0
Southeast Asia	confidential	12.0
Africa	confidential	42.0
Oceania	confidential	5.0
Mid East	confidential	1.0
Eastern Asia	confidential	3.0
Central America	confidential	4.0
South Asia	confidential	7.0
Domestic Market	confidential	18.0

Production Machinery:

Machine Name	Brand & Model No.	Quantity	Number of Year(s) Used	Condition
Punching Machine	JB23-63A	4	7.0	Acceptable
Sawing Machine	No Information	4	7.0	Acceptable
Drilling Machine	ZQ4-16	13	3.0	Acceptable
Bending Machine	WC67Y, SCFHB-001	4	7.0	Acceptable
Shearing Machine	QC12Y-4*4000	2	7.0	Acceptable
Coreboard Production Line	No Information	3	7.0
