Home > Products > Prefabricated House > prefabricated modern modular house , dismantled and moved house
prefabricated modern modular house , dismantled and moved house
US$ 60 - 80
/ Unit
1 Unit(Min. Order)
- Xingang(tianjin)
- T/T Credit Card
You May Like
-
china Fast installation and steel structure prefab buildings
-
K type China manufacturer economic prefabricated kitchen dinning
-
High quality steel modular housing for mining and construction site worker accommodation
-
Pre built Buildings for building and construction company
-
ISO9001 certified low cost light steel china ready steel houses made in china
-
ready made prebuilt mobile container house
Product Details
| Place of Origin | Beijing, China | Brand Name | CDPH | |
| Model Number | A Type house | Material | Steel | |
| Use | Carport, Hotel, House, Other, Shop, Toilet, Warehouse, Carport, Hotel, House, Kiosk,Booth, Sentry Box,Guard House, Shop, Toilet, Warehouse, Workshop,Plant |
Product Description
Prefabricated house (A type) is a standard modular house. The width is 5.048m as fixed size but the inside layout can be designed as per customers’ requirements. When delivery, it is knock-down to save space. Based on bolts connection without welding work, it could be assembled and disassembled easily and four workers can finish 120m2 in 8 hours according to instruction and CD.
The detailed information as follow:
| No. | Main Item | Subitem | Specification | Remark | |
| 1 | Basic Information | Product Item | Stardard Position | Standard | / |
| 2 | Possibility of Reassemble | Suitable for disassembled and reassembled | / | ||
| 3 | Basic Specification | Span | 5060mm | Fixed | |
| 4 | Length | (n-2)*1224+2*1106mm | n is integer,and 4≤n≤40 | ||
| 5 | Wall Height | 2700mm | / | ||
| 6 | Net Height | 2700mm | / | ||
| 7 | Ridge Height | 3750mm | / | ||
| 8 | Technical Data | Roof Live Load | 0.3 KN/m2 | / | |
| 9 | Wind Load | 0.45 KN/m2 | / | ||
| 10 | Suitable Temperature | (-)15°C~(+)50°C | / | ||
| 11 | Material Data | Structure | Column | cold bend steel plate | grey color |
| 12 | Main Beam | ||||
| 13 | Tie Rod | steel plate bending | galvanized and painting | ||
| 14 | Floor Beam | steel plate bending | anti-rust painting | ||
| 15 | Items Required to Maintain | Wall Panel | 50mm color steel sandwich panel | white in double side | |
| 16 | Roof Panel | 60mm color steel sandwich panel | top:blue bottom:white | ||
| 17 | Door | outdoor:sandwich panel door | EPS insulation | ||
| 18 | indoor:sandwich panel door | EPS insulation | |||
| 19 | Window | color steel sliding window | blue | ||
| 20 | Installation | Tools | spanner, tape, etc. | requiring electric power at working site | |
| 21 | Efficiency | (construction area)120m2 per day by four people(Main Structure) | simple training | ||
| 22 | Loading | Square Meter | around 350m2/40 HC(Main Structure) | / | |
