Home > Products > Milling machine > HM1668 Heavy Duty Universal Milling Machine
HM1668 Heavy Duty Universal Milling Machine
US$ 7,600 - 10,000
/ Set
1 Set(Min. Order)
- FOB Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | |||
| Brand Name | TZhising | Model Number | HM1668/HM1360, HM1668/HM1360 | |
| Type | Universal | CNC or Not | Normal | |
| Voltage | Customer Requirement | Power(W) | 5.5kw | |
| Dimension(L*W*H) | 1800x2100x2200mm | Weight | 2700kg | |
| Certification | ISO9001:2008 | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specification of Univeral milling machine HM1668/HM1360:
| Model | HM1668 | HM1360 |
| Worktable size | 400x1700(16''x68'') | 340x1500(13''x60'') |
| Worktable travel | 1110x400x400mm | 850x330x400mm |
| T-slot of table(number-width-length) | 5-20-80mm | 3-20-80mm |
| Spindle taper | ISO40(vertical) ISO50(horizontal) | ISO40(vertical) ISO50(horizontal) |
| Spindle speed.(range/steps) | 40-1200r.p.m | 40-1300r.p.m 12 steps |
| Distance from spindle axis to column | 0-415mm | 430mm |
| Range of worktable travel | 30-400mm/min 10steps | 30-400mm/min 10 steps |
| Rapid feed of worktable | 900mm/min | 900mm/min |
| Max.rotation angle of table | ±45° | ±45° |
| Main motor power | 5.5kw | 3kw |
| Motor for rapid device of table | 1.1kw | 0.75kw |
| N./W | 27000kg | 1700kg |
Photo of HM1668 Heavy Duty Universal Milling Machine:
Contact Us
- Tengzhou Hising Machine Tools Co., Ltd.
- Contact nameXueyao Pei Chat Now
- Phone86-632-5689986
- AddressEast End Of Xingteng Road, Industrail Park
