factory direct sales sections air Cylinder DNC Series ISO6431FESTO standard

FOB Price

USD $10 - $100 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Cylinder		Place of Origin	Zhejiang, China
Model Number	DNC		Brand Name	AIPHONSO

bore from 32~125, stroke from 25~1000
ISO15552,VDMA/ISO6431 pneumatic air cylinder
competitive price

Standard Pneumatic Cylinder
Standard Air Cylinder
* DNC Series ISO6431 /VDMA 24562 ( FESTO TYPE )
ISO15552

* Conform to ISO6431 and VDMA 24562 standard pneumatic cylinder;

* DNC Series are with similar FESTO DNC appearance, with slot on the cylinder barrel and end covers for magnet sensor mounting more conveniently;

* DNC series are with FESTO style and cover and mickey mouse barrel to be cost effective;

* Adjustable cushion on both cylinder end covers to make sure the cylinder works very smoothly safely and with low noise;.

* With self-lubricating bearing,the piston rod is lubrication free.

* Magnet and sufficient Fixing styles are available.

Inner diameter(mm)	32	40	50	63	80	100	125
Motion Pattern	Double Action Type
Working medium	Air
Fixed type	Basic type, FA type, Fb type,CA type,CB type,CR type, LB type,TC type,TC-M type
Working pressure	0.1~0.9MPa
Ensured Pressure Range	1.35MPa
Operating Temperature	-5~70 degree centigrade
Operating Speed Range	50~800 mm/s
Buffer type	Adjustable Buffer
Buffer Stroke	24						32
Joint pipe bore	PT1/8"	PT1/4"		PT3/8"		PT1/2"
