Semi-automatic Plastic Bottle Blow Molding Machine GS8Y1
- SHANGHAI
- Credit Card PayPal
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | Yes | Place of Origin | Shanghai, China | |
| Brand Name | GS, GS | Model Number | GS8Y1, GS8Y1 heat-resistant bottle blowing | |
| Certification | ISO9001-2000 |
Product Description
Specifications
Capacity: 800pcs/hr (based on 500ml)Max volume of product: 2 liters
GS8Y1 semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 10-2000ml. It is widely used to produce the carbonated bottle ,mineral water,carbonated drink bottle.
SPECIFICATION
Main parameter: | ||
Model | GS8Y1 | |
Container | Product material | PET |
Volume | 0.1L-2L | |
Theoretical output | 600-800PCS/H | |
Preform length | 15mm-350mm | |
Preform inner diameter | 5mm-38mm | |
Moulding | Max.mould plate Dimenstion(L x W) | 350x380mm |
Max.mould thickness | 180mm | |
Clamping force | 45KN | |
Mould opening stroke | 16mm | |
Machine size and weight | Main machine (L x W x H) | 160x60x161cm |
Main machine weight | 500Kg | |
Heater (L x W x H) | 187x63x145cm | |
Heater weight | 250Kg | |
Power | 17.5kw | |
